MTL5046– MTL Communication Isolator | Original New

MTL5046 Hazardous Area Driver – Smart 4-20mA Signal Converter with Digital Comms

Core Features

The MTL5046 safely drives 4-20mA signals into Zone 0/Div.1 hazardous areas. It adds bi-directional digital communication and line fault detection for smarter control.

Technical Performance

• Brand: MTL | Model: 5046 (Full suffix: MTL5046-EX-COM)
• Signal Range: 4-20mA (1-24mA fault range)
• Load Resistance: 100Ω to 800Ω
• Digital Bandwidth: 500Hz-10kHz
• Accuracy: ±0.05% (10μA max error)
• Response: 100μs (10% settling)
• Voltage Drop: <4V @20mA
• Power: 20-35V DC

Special Functions

• Line Fault Detection (LFD): >100kΩ impedance change
• HHC Support: Hand-held communicator ports
• Dual Connectors: HAZ 4-6 & SAF 7-9 required

5 Expert FAQs

1. Can MTL5046 work with PLC systems?
   Yes, connects directly to most PLC analog inputs.
2. How does LFD work?
   Auto-detects cable breaks via impedance monitoring.
3. Is calibration needed for digital signals?
   No, self-tuning for 500Hz-10kHz range.
4. What’s the max operating temperature?
   60°C continuous operation.
5. Can I daisy-chain multiple units?
   No, each MTL5046 needs direct wiring.

What’s Included

• 1x MTL5046 unit
• Installation sheet
• 12-month quality guarantee
• Worldwide shipping via FedEx/UPS/DHL
