MTL5553 Fieldbus Isolator – Hazardous Area Network Extender for H1 Systems

Industrial Fieldbus Solution

The MTL5553 safely extends 31.25kbit/s fieldbus networks into Zone 0, IIC hazardous areas. Provides power and communication with switchable termination for flexible installations.

Key Specifications

• Brand: MTL | Model: 5553 (Full code: MTL5553-EX-FB)
• Fieldbus Speed: 31.25kbit/s (H1 compliant)
• Output Power: 18.4V ±2% @80mA max
• DC Impedance: 105Ω ±3%
• Isolation: 250V AC safe/hazardous area
• Supply Voltage: 20-35V DC
• Power Consumption: 135mA @24V
• Certification: ATEX/IECEx Zone 0, IIC

Installation Features

• Switch-selectable termination for short networks
• DIN-rail mounting (vertical recommended)
• 10mm spacing required between units
• Green LED power indicator

5 Fieldbus FAQs

1. When should I enable termination?
   For safe-area bus lengths under 30 meters.
2. Can I daisy-chain multiple devices?
   Yes, within the 80mA power limit.
3. What cable type is recommended?
   Type A fieldbus cable for best performance.
4. How to calculate max cable length?
   Based on IS parameters and voltage drop.
5. Is special configuration needed?
   No, plug-and-play operation.

Package & Support

• 1x MTL5553 isolator unit
• Quick-start guide
• DIN-rail mounting clip
• 12-month performance warranty
• Express shipping via FedEx/UPS/DHL
