Product Introduction
Protect your critical measurements with this Bently Nevada Proximity Probe Housing Assembly. Model 31000-28-10-00-010-01-02 provides robust environmental protection for sensitive vibration probes.
Key Features & Advantages
- Complete Protection: IP66 and NEMA 4X ratings guard against water and dust
- Hazardous Area Ready: Certified for use in explosive atmospheres
- Complete Kit: Includes 3300 XL 8mm probe with 1.0 meter cable
- Easy Installation: Standard 3/4-14 NPT mounting thread
- Durable Construction: Conductive PPS housing with stainless steel components
Configuration Breakdown
- Complete Assembly Number: 31000-28-10-00-010-01-02
Technical Specifications
- Environmental Protection
- Ingress Protection: IP66 certified
- NEMA Rating: Type 4X
- Hazardous Area: CENELEC EN50014 compliant
- Temperature Range: -51°C to +105°C
- Impact Resistance: 7 Joule at room temperature
- Physical Construction
- Housing Material: Conductive glass-reinforced PPS
- Internal Sleeve: AISI 304 stainless steel
- External Hardware: AISI 303 stainless steel
- Sealing: Neoprene O-rings
- Mounting Thread: 3/4-14 NPT standard
- Weight: 1.2 kg (2.6 lb) typical
- Mechanical Performance
- Retaining Nut Torque: 29.4 N·m (260 in-lb)
- Structural Strength: Supports 912 N load at 38mm
- Probe Type: 3300 XL 8mm diameter
- Cable Length: 1.0 meter included
- Probe Extension: 1.0 inch into housing
Ordering Information
- Warranty Coverage: Comprehensive 12-month warranty included
- Shipping Methods: Available via FedEx, UPS, DHL worldwide
- Package Contents: Complete housing assembly with probe
- Technical Support: Expert assistance available
- Email: info@oiltechcontrols.com
- WhatsApp: +86 158 8020 0923
Expert Questions & Answers
What environments is this housing designed for?
It’s perfect for outdoor installations, wet areas, and hazardous locations where dust, water, or explosive atmospheres are concerns.
Is the included probe replaceable?
Yes, the 3300 XL 8mm probe can be replaced if damaged. Follow proper installation procedures for O-ring sealing.
What does IP66 rating mean for my application?
IP66 means complete protection against dust ingress and powerful water jets. Ideal for washdown areas or outdoor installations.
Can this housing withstand mechanical impact?
Yes, it’s certified to withstand 7 Joule impacts at room temperature and 4 Joule impacts at extreme temperatures.
How do I select the right penetration length?
The 1.0 inch penetration works for most applications. For special requirements, contact us about custom configurations.
