Schneider 140HRT10000 Modicon Quantum Interface Module

🔹 Schneider Electric 140HRT10000 – Modicon Quantum Interface Module

The 140HRT10000 is a tough interface module built for smooth data flow in Modicon Quantum systems. It handles 0 to 60 °C temps naturally – no fan needed. Metal case, easy mount, and ready for demanding industrial comms.

📦 Quick specs – what you get

• Part number : 140HRT10000 · type : communication interface
• Cooling : natural convection – silent, no moving parts
• Material : rugged metal housing for harsh floors
• Mounting : through screw holes – secure & fast
• Temp range : 0 °C to +60 °C (operating & storage)
• Humidity : 80% max, non‑condensing
• Altitude : 1000 m without derating – works at height
• Protection : IP20 (indoor, finger‑safe)
• Standards : CE marked – EU compliant

💡 Why choose this module? – selling points

• Plug‑and‑play data integration for Quantum automation
• No derating up to 1000 m – ideal for high‑altitude plants
• Wide humidity tolerance 80% – stable in damp control rooms
• Metal enclosure resists impact and EMI better than plastic
• Natural cooling means zero maintenance and lower energy use
• Universal mounting with screw holes fits any backplate

🔧 Installation & environment

• Mounting : use M4 or M5 screws through the holes – torque to 1.5 N·m
• Keep indoor, dry : IP20 protects from tools & small dust, but not water
• Air flow : leave 25 mm clearance top/bottom for natural convection
• Wiring : use shielded twisted‑pair for best signal quality (refer to Quantum manual)

📞 Contact & support

• Email: info@oiltechcontrols.com
• WhatsApp: +86 158 8020 0923 (click for direct chat)
• Warranty : 12 months against defects · shipping : FedEx, UPS, DHL worldwide

❓ 5 professional FAQs – real‑world answers

• Q: Can the 140HRT10000 be used in a panel with other heat‑producing modules?A: Yes, it uses natural cooling, but ensure 25 mm space above and below. Keep ambient below 60 °C inside the enclosure.
• Q: Does this module need special software or drivers?A: It works with standard Quantum backplane and Unity Pro / Control Expert. No extra drivers – just configure the I/O mapping.
• Q: I have an old Quantum rack – will it fit?A: Absolutely. The 140HRT series fits any Quantum XBus backplane (like 140XBPxxx). Screw holes align perfectly.
• Q: What does IP20 actually protect against?A: It stops fingers and tools >12.5 mm, and light dust. It is not waterproof – keep away from drips and hose‑down areas.
• Q: Can I use this module at 2000 meters altitude?A: Without derating? No – above 1000 m you must reduce max ambient temperature by about 0.5 °C per 100 m. Contact us for high‑altitude calc.
