Schneider Electric 140ACI04000 Analog Input Module | Modicon Quantum

Schneider Electric Modicon Quantum 140ACI04000 Analog Input Module

Product Overview

• The 140ACI04000 is a high-performance analog input module from Schneider Electric.
• This module belongs to the renowned Modicon Quantum automation platform family.
• It provides sixteen differential input channels for flexible system integration.
• The module supports multiple current ranges to suit various application needs.
• You can use it in diverse industrial environments with reliable performance.

Key Technical Specifications

• Brand: Schneider Electric
• Model: 140ACI04000
• Product Type: Analog Input Module
• Input Channels: 16 differential inputs
• Resolution: Up to 25,000 counts for 0-25 mA range
• Absolute Accuracy: ±0.125% of full scale
• Update Time: 15 milliseconds for fast response
• Input Impedance: 250 Ohm for stable signal reading
• Common Mode Rejection: >90 dB at 60 Hz for noise immunity
• Isolation: 1780 V AC for 60 seconds for safety
• Filter Type: Single pole low pass, 3 dB at 34 Hz
• Broken Wire Detection: Supported for 4-20 mA range

Operating Environment & Certifications

• Operating Temperature: 0 to 60 °C (32 to 140 °F)
• Storage Temperature: -40 to 85 °C (-40 to 185 °F)
• Relative Humidity: 95% without condensation forming
• Operating Altitude: Up to 5000 meters (16404 feet)
• ESD Protection: 4 kV contact and 8 kV air per IEC 801-2
• EMC Immunity: 10 V/m from 80 to 1000 MHz per IEC 801-3
• The module meets UL 508, CSA C22.2 No 142, and FM Class 1 Division 2 standards.

Module Status Indication & Power

• Bus Communication: One green LED shows active communication.
• External Fault: One red LED indicates a system fault.
• Channel Status: Sixteen green LEDs show active channels.
• Channel Fault: Sixteen red LEDs indicate channel errors.
• Bus Current: Requires 360 mA from the backplane.
• Power Dissipation: 5 Watts under normal operating conditions.

Installation & Addressing

• The 140ACI04000 module uses a standard format for easy installation.
• Your system requires seventeen input words for proper module addressing.
• Ensure the operating environment stays within the specified temperature range.
• This module weighs only 0.3 kg (0.7 lb) for simple handling and mounting.

Packaging & Shipping Details

• We ship each module in a secure individual package for full protection.
• The package dimensions are 31.0 cm x 16.5 cm x 4.6 cm (12.2″ x 6.5″ x 1.81″).
• The total shipping weight with packaging is 433 grams (15.3 ounces).
• We ship all orders via reliable carriers like FedEx, UPS, and DHL.

Frequently Asked Questions

• What input types does this module support? It supports differential inputs.
• Does it detect broken wires? Yes, for the 4-20 mA input range.
• What is the module’s update speed? It updates all channels in 15 ms.
• How many channels does the module have? It provides sixteen input channels.
