Streamlined Connectivity: Schneider Electric 140CFA04000 Wiring Solution
Universal Wiring Block Overview
- The 140CFA04000 provides efficient point-to-point wiring for Quantum systems.
- This Schneider Electric accessory simplifies installation and maintenance processes.
- It works with all Modicon Quantum I/O modules except thermocouple type 140ATI03000.
- You get thirty-two organized connections in a single compact wiring block.
- The integrated fuse protection enhances system safety and reliability.
Key Technical Specifications
- Brand: Schneider Electric
- Model: 140CFA04000
- Product Type: CableFast Terminal Block with Fuses
- Connection Points: 32 individual wiring contacts
- Connector Type: 50-pin female SUB-D interface
- Terminal Style: Captive screw terminals for secure connections
- Wiring Method: Straight through point-to-point configuration
- Mounting System: Standard 35mm DIN rail compatible
- Contact Material: High-conductivity copper alloy
- Insulation Resistance: >100 MΩ at 500V DC
- Dielectric Strength: 2500V AC for 60 seconds
- Temperature Rating: -40°C to +85°C operational range
- Wire Range: Accepts 12-28 AWG conductors
Installation & Compatibility
- The block mounts quickly on standard DIN rails without special tools
- It connects seamlessly to all Quantum I/O modules using the SUB-D connector
- Captive screw terminals prevent lost hardware during installation
- Clear marking labels identify each connection point for easy wiring
- The straight-through design simplifies troubleshooting and maintenance
- Integrated fuse holders provide circuit protection for connected devices
- The compact design saves valuable panel space in control cabinets
Shipping & Packaging Information
- Each unit ships in protective packaging ensuring perfect condition
- Package dimensions measure 26.8cm × 18.3cm × 11.0cm (10.55″ × 7.20″ × 4.33″)
- Total shipment weight with packaging is 393 grams (13.86 ounces)
- We ship worldwide using FedEx, UPS, and DHL express services
- All purchases include 12-month comprehensive warranty coverage
Professional Application FAQ
- What Quantum modules are compatible with this wiring block?
- The block works with all Quantum I/O modules except the 140ATI03000 thermocouple module.
- What wire sizes can I use with the terminal blocks?
- The terminals accept standard industrial wire sizes from 12 AWG to 28 AWG.
- Does this wiring block include fuses?
- Yes, it comes with integrated fuse holders for complete circuit protection.
- What mounting hardware do I need for installation?
- The block requires standard 35mm DIN rail and no additional mounting hardware.
- Can I use this for both digital and analog modules?
- Yes, the universal design supports both digital and analog Quantum I/O modules.
