Schneider Electric 140CFJ00400 – Output Block | Modicon Quantum PLC

Premium Fused Analog Output Block: Schneider Electric 140CFJ00400

• The Schneider Electric 140CFJ00400 fused analog output block for Modicon Quantum.
• Individual fuse protection for each analog channel
• Complete signal and power interfaces
• Superior 6-terminal point design
• Dual power supply flexibility
• Professional shielded connections

Product Specifications

Brand: Schneider Electric

Model: 140CFJ00400 (Complete Suffix)

Product Type: Fused Analog Output Block

Output Channels: 4 protected points

Fuse Rating: 0.063A per channel

Terminals per Point: 6 dedicated terminals

Connector Type: SUB-D 50 female

Mounting: Standard DIN rail

Terminal Style: Captive screw design

Interfaces: Plus, minus, shield, power

Power Options: Field and loop power

Dimensions: 10.5cm H x 18cm W x 26.5cm L

Weight: 416 grams

Module Compatibility

Specifically designed for 140ACO02000 analog output module. Perfect signal matching and protection.

Easy Installation

Simple DIN rail mounting. Quick SUB-D 50 connection. Clear terminal identification.

Advanced Protection

Individual 0.063A fusing per channel. Complete shielding. Dual power isolation.

Package Contents

One 140CFJ00400 fused analog output block. Ready for immediate installation and use.

Warranty & Shipping

12-month reliability warranty. Fast delivery via FedEx, UPS, DHL. Order today for quick shipping.

Technical Questions

How many terminals per output channel?

6 terminals per channel for complete signal and power management.

What is the fuse rating for each channel?

0.063 Amp individual fuse protection per analog output.

Which module is compatible with this block?

Designed specifically for the 140ACO02000 analog output module.

What power configurations are supported?

Both field power and loop power supply interfaces included.

What signal connections are provided?

Plus, minus, shield, and power supply terminals for each point.
