Product Overview
The Schneider Electric 170ADM35015 delivers fast and stable DC input and output control for Modicon Momentum systems.
I/O Structure
- Provides 16 discrete inputs compliant with IEC 1131-2 Type 1
- Includes 16 solid-state outputs for reliable DC switching
- Designed for compact distributed automation panels
Electrical Characteristics
- Input voltage range: 3–30 V DC
- Output voltage: Up to 30 V DC, 24 V DC nominal
- Negative logic design for simple system wiring
Current and Load Capacity
- Input current at state 1: ≥ 2.5 mA
- Output current per channel: 0.5 A
- Total output capacity: 8 A per module
Speed and Isolation
- Input response time: 2.2 ms on, 3.3 ms off
- Output response time: < 0.1 ms
- Electrical isolation: 500 V AC between channels and bus
Thermal and Power Limits
- Power dissipation remains below 8 W
- Operating temperature range: 0°C to 60°C
- Suitable for continuous industrial operation
Product Details
- Brand: Schneider Electric
- Series: Modicon Momentum
- Model: 170ADM35015
- Weight: Approx. 0.50 lb (0.23 kg)
Packaging, Warranty, Shipping
- Package includes one DC solid-state I/O module
- 12-month warranty from shipment date
- Worldwide shipping via FedEx, UPS, and DHL
FAQ
- What applications use this module?
- DC control systems with sensors, relays, and actuators
- Why choose solid-state outputs?
- They offer faster switching and longer service life
- How do I manage output current limits?
- Distribute loads evenly across output groups
- What warranty is included?
- A standard 12-month warranty is provided
- Which shipping methods are available?
- FedEx, UPS, and DHL are available worldwide
