Schneider Electric 170XTS00701 Modicon Momentum Busbar Connector
The 170XTS00701 is a dedicated busbar connector from Schneider Electric. It provides critical integration for Modicon Momentum automation systems. This component links discrete and analog I/O bases efficiently. It ensures reliable electrical connections in industrial control panels. Oiltech Controls supplies this genuine Schneider Electric part.
Key Product Features & Benefits
- Brand & Model: Genuine Schneider Electric part, model 170XTS00701.
- Core Function: Enables power and signal distribution across Momentum I/O bases.
- Connection Type: Spring-type terminals allow for fast, tool-less wiring.
- Robust Design: High-conductivity metal ensures excellent electrical performance.
- Wide Temperature Range: Operates reliably from -25°C to +70°C.
- Compact Form: Single horizontal row design saves valuable panel space.
Complete Technical Specifications
- Manufacturer / Brand: Schneider Electric
- Part Number / Model: 170XTS00701
- Product Line: Modicon Momentum
- Type: 1-Row Busbar Connector
- Compatibility: Discrete and Analog I/O Bases
- Terminal Design: Spring-Type (Push-in)
- Configuration: Single Horizontal Row
- Construction: High-Conductivity Metal Alloy
- Operating Temperature: -25°C to +70°C
- Electrical Performance: Low-Resistance, High-Conductivity
- Durability: Vibration-Resistant Design
- Mounting: Plug-In Mechanism for Easy Installation
- EAN Code: 3595861147881
Installation & Mounting Guide
- Ensure the Modicon Momentum rack is powered off before installation.
- Align the 170XTS00701 connector with the guide slots on the I/O base.
- Gently push the connector straight into place until it clicks securely.
- Use the spring terminals by inserting a screwdriver to open the clamp.
- Insert the stripped wire and release the clamp for a gas-tight connection.
- Verify all connections are secure before applying power to the system.
Packaging & Shipping Details
- Package Contents: 1 x Schneider Electric 170XTS00701 Busbar Connector.
- Packaged in protective industrial-grade blister or box.
- Standard shipping via global carriers: FedEx, UPS, or DHL.
- Tracking information is provided upon dispatch from our warehouse.
- For bulk orders, contact us for custom shipping solutions.
Frequently Asked Questions (FAQ)
- Q: What is the main purpose of this 170XTS00701 connector?
- A: It distributes power and signals between I/O modules within a Modicon Momentum rack, replacing individual wiring.
- Q: Is this connector compatible with all Momentum I/O modules?
- A: Yes, it is designed to work with both discrete (digital) and analog Momentum I/O bases.
- Q: What are the advantages of spring-type terminals?
- A: They enable faster installation, require no screw tightening, and maintain consistent contact pressure.
- Q: Can this busbar handle high-vibration environments?
- A: Absolutely. Its design and secure plug-in mount resist loosening under vibration.
- Q: How do I choose between different Momentum busbar models?
- A: The 170XTS00701 is the standard 1-row connector. Confirm your rack model and required number of rows.
- Q: From an integrator’s experience, what’s a key installation tip?
- A: Always pre-plan your wire routing before snapping the busbar in. It’s harder to organize wires after installation.
Ordering & Technical Support
- For pricing, availability, and technical questions about the 170XTS00701:
- Email: info@oiltechcontrols.com
- Phone/WhatsApp: +86 158 8020 0923
- Author: Oiltech Controls – Your Partner for Industrial Automation Components.
