Product Introduction
This is the Schneider Electric ABFC08R12R commoning link. It is part of the Modicon Momentum series. This small red component makes electrical connections simple and efficient. It is perfect for use in compact automation control cabinets.
Key Features & Benefits
- Compact Design: Small size saves valuable space inside control panels.
- Easy Identification: Distinctive red color for quick visual location.
- Lightweight & Durable: Weighs only about 20 grams for easy handling and installation.
- Wide Compatibility: Designed specifically for the Modicon Momentum series modules.
- Reliable Performance: Stable operation in a wide temperature range from 0°C to 60°C.
- Standard Certification: CE marked, ensuring safety and quality compliance.
Detailed Technical Specifications
- Brand: Schneider Electric
- Product Line: Modicon Momentum
- Model Number: ABFC08R12R
- EAN Code: 3389110449273
- Color: Red
- Dimensions (LxWxH): 80 mm x 70 mm x 7.9 mm (3.15″ x 2.76″ x 0.31″)
- Weight: Approximately 0.02 kg
- Rated Current: Suitable for signal and low-power circuit connections.
- Insulation Material: Flame-retardant engineering plastic.
Environmental & Compliance
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -25°C to +70°C
- Operating Humidity: ≤95% (non-condensing)
- Storage Humidity: ≤95% (non-condensing)
- Maximum Altitude: 1000 meters above sea level
- Key Certification: CE Mark (Conformité Européene)
- Pollution Degree: 2
Warranty & Shipping
This product comes with a 12-month warranty from the shipment date. We ship globally via FedEx, UPS, and DHL. Tracking information will be provided after dispatch.
Frequently Asked Questions
Product Application
Where exactly is this commoning link used?
It is primarily used to connect the common terminals of Modicon Momentum I/O modules, for example, to quickly link the power ground or signal reference ground of multiple modules together.
How much current can it handle?
It is designed for signal and low-power circuits. For high-current power connections, please consult the manual and use dedicated power distribution components.
Installation & Usage
Are there any precautions during installation?
Ensure the system is powered off. Firmly snap it onto the corresponding connection points of the module until you hear a “click”. Avoid installation in excessively damp or dusty environments.
The link feels a bit loose. Will this affect performance?
Yes. A loose connection can cause signal interruption or power issues. Check if it is correctly seated or if the module’s connection points are damaged.
Purchasing Guidance
How do I confirm if the ABFC08R12R is compatible with my Momentum modules?
Please check your Momentum module model number. This link is a universal accessory for the Momentum series. If unsure, you can provide your module model to us for verification.
