SICK NANS3-AAAZ30AN1 NanoScan3 Safety Laser Scanner | Type 3 SIL 2 PL d

Product Introduction

The SICK NANS3-AAAZ30AN1 is a NanoScan3 safety laser scanner. It provides reliable area protection for machines. This model meets Type 3 safety standards. It is perfect for indoor automation safety.

Key Safety Specifications

• Model: SICK NANS3-AAAZ30AN1 NanoScan3 Core I/O
• Safety Rating: Type 3, SIL 2, PL d (Category 3)
• Scanning Angle: Wide 275° coverage area
• Range: 40m detection, 3m protective, 10m warning
• Response Time: Fast 70 milliseconds
• Field Monitoring: Up to 4 fields simultaneously
• Resolution: Configurable from 20mm to 200mm
• Angular Resolution: Precise 0.17°
• PFHD: High reliability: 8.0 x 10⁻⁸

Technical Features & Design

• Interfaces: Ethernet data output, USB 2.0 config
• I/O: 3 Universal I/Os, 1 OSSD pair
• Display: Graphic color display with LEDs
• Housing: Aluminum, IP65 rated for protection
• Dimensions: 106.6 x 80 x 117.5 mm
• Weight: Light 0.67 kg
• Laser: Class 1, 905 nm wavelength
• Temperature: Operates -10°C to +50°C

Reliability & Support

• Mission Time: 20 years design life
• Vibration: Meets IEC 60068-2-6 standards
• Software: Configure with Safety Designer PC software
• Warranty: 12-month manufacturer coverage
• Shipping: Worldwide via FedEx, UPS, DHL
• Support Contact: info@oiltechcontrols.com
• Phone Support: +86 158 8020 0923

FAQ – Installation & Application

• What does “Type 3” safety rating mean?
  Type 3 means single faults won’t cause safety loss. The system has diagnostic coverage for reliability.
• Can I use this scanner outdoors?
  No. The NANS3-AAAZ30AN1 is for indoor use. Its IP65 rating protects against dust and water jets.
• How many safety zones can I create?
  You can configure up to 8 different fields. The scanner can monitor 4 of these fields at the same time.
• What is the best mounting height?
  Mount between 200-300mm above floor level. This height detects legs and feet effectively.
• Do I need special training to configure it?
  Yes. Use SICK’s Safety Designer software. Proper training ensures correct safety function setup.
