SICK S30B-3011DA S300 Professional Safety Laser Scanner
The S30B-3011DA protects people and machines.
It scans wide areas with high accuracy.
It is built for indoor safety zones.
Product Identity
- Brand: SICK
- Series: S300 Professional
- Model: S30B-3011DA
- Type: Safety laser scanner
- Application: Indoor use
Scanning and Detection Performance
- Protective field range up to 3 m
- Warning field range up to 8 m
- Maximum measuring distance 30 m
- Scanning angle 270 degrees
- Angular resolution 0.5 degrees
Field Configuration Flexibility
- Triple field set design
- Total of 8 field sets
- Up to 24 configurable fields
- Supports 32 monitoring cases
- Automatic reset delay adjustable
Safety and Compliance Ratings
- Safety integrity level SIL 2
- Performance level PL d
- Category 3 architecture
- PFHD 8.0 x 10⁻⁸ per hour
- Mission time up to 20 years
Electrical and Interface Details
- Operating voltage 24 V DC
- Voltage range 16.8 to 30 V DC
- Two OSSD safety outputs
- RS-232 for setup and diagnostics
- RS-422 and EFI communication
Mechanical and Environmental Design
- Aluminum die-cast housing
- IP65 enclosure rating
- Operating temperature -10 to 50 °C
- Shock resistance up to 16 g
- Compact size and 1.2 kg weight
Main Product Benefits
- Wide area safety coverage
- Fast response time of 80 ms
- Flexible safety field setup
- Strong resistance to vibration
- Trusted SICK safety technology
Warranty and Logistics
- Warranty period 12 months
- Worldwide shipping available
- Delivery via FedEx
- Delivery via UPS
- Delivery via DHL
Professional FAQ
- Is this scanner suitable for robot cells?
- Yes. It supports flexible safety zones.
- Can field sizes be changed later?
- Yes. Configuration is done by software.
- Does it work in dusty environments?
- Yes. IP65 housing protects the optics.
- How do I choose the correct range?
- Match protective field to stop distance.
- Is this model suitable for high safety levels?
- Yes. It meets SIL2 and PL d.
