6FC5111-0CA03-0AA2 – Siemens Output Module · 8-Channel 24V DC
Siemens · I/O Modules series · floating, isolated outputs · 2 A per channel.
Product Overview
The Siemens 6FC5111-0CA03-0AA2 output module provides eight isolated 24 V DC outputs. Each channel supports up to 2 A continuous current. Designed for harsh industrial use, it includes short-circuit protection and freewheeling diodes for inductive loads. Panel mount with IP20 rating ensures stable operation in control cabinets.
Technical Specifications
| Manufacturer | Siemens · Germany |
| Part Number / EAN | 6FC5111-0CA03-0AA2 · EAN 4025515006084 |
| Number of Outputs | 8 (floating, isolated) |
| Output Voltage / Current | 24 V DC · 2 A per channel (max.) |
| Current Consumption | 40 mA (internal logic) |
| Protection & Diagnostics | Short-circuit protected · integrated freewheeling diode |
| Temperature Range | 0 °C to +50 °C (operating) |
| Environmental Protection | IP20 (dust-proof, touch-proof) |
| Mounting / Weight | Panel mount · 0.45 kg |
| Linearity / Resolution | Digital output · ON/OFF response < 1 ms |
| Interference Immunity | EN 61000-6-2 (industrial environment) |
- Floating & isolated outputs – eliminate ground loop problems.
- Short-circuit proof – automatic shutdown on fault.
- Freewheeling diode per channel – handles inductive loads (relays, solenoids).
- Current consumption only 40 mA – very efficient.
- IP20 protection – suitable for clean, dry panels.
- Temperature range 0…50 °C – stable on factory floors.
- Panel mount – fast installation with standard hardware.
Installation, Commissioning & Diagnostics
- Mounting: panel mount with M4 screws. Optional DIN rail adapter.
- Wiring: spring-clamp terminals; accepts 0.5–2.5 mm² wire.
- Diagnostic LED: green “PWR” and per-channel red fault indicator.
- Short-circuit detection: auto-recovery after fault removal.
- Commissioning: plug-and-play with Siemens TIA Portal or STEP 7.
- Maintenance: no calibration needed; periodic dust cleaning.
Compatibility & Certifications
- Compatible with Siemens S7-300, S7-400, ET200M series.
- Certifications: CE, UL (pending), RoHS compliant.
- Meets EN 61131-2 and IEC 61000-6-4 EMC standards.
- Works with third-party PLCs via 24V DC I/O interface.
Typical Applications
- Actuator control in conveyor systems
- Valve and solenoid driver in process automation
- Signal lamp and indicator output in machine tools
- Relay replacement in legacy control panels
- Distributed I/O for factory automation
Package, Shipping & Warranty
- ✔ Package includes: 1x module, terminal connector set, mounting screws, quick guide.
- ✔ Shipping carriers: FedEx, UPS, DHL – express worldwide.
- ✔ Warranty: 12 months against manufacturing defects.
- ✔ Obsolete support: we verify and test legacy systems before shipment.
Why Buy from Oiltech Controls?
- ✅ 15+ years industrial automation spare parts experience.
- ✅ Global shipment – fast and insured delivery.
- ✅ Every unit technically verified before dispatch.
- ✅ Refurbished / surplus options with full test reports.
- ✅ 12-month warranty – peace of mind for obsolete parts.
- ✅ Support for legacy control systems – we keep your line running.
FAQ – Quick Answers
- Q: Is this module compatible with S7-1200?
A: Yes, via 24V DC digital output interface (adapter cable needed). - Q: Can I use it for 230V AC loads?
A: No, it is rated for 24V DC only. Use external relays for AC. - Q: Does it support hot-swapping?
A: No, power off before installation or removal. - Q: What diagnostic features are available?
A: Per-channel LED fault indication and short-circuit reporting. - Q: Is the 12-month warranty transferable?
A: Yes, it covers the product for the end user within the period.
