Core Product Features
- Controls three independent movement axes.
- Handles both fast and slow speed drives.
- Works with Siemens SIMATIC S7-400 PLC systems.
- Includes setup software on a CD.
- Robust design for factory floor use.
Detailed Technical Specifications
- Power & Electrical:
- Needs 24V DC power supply.
- Uses about 550 mA of current.
- Generates 3.6 Watts of heat.
- Encoder Connections:
- 5V encoder power: 210 mA max.
- 24V encoder power: 300 mA max.
- Accepts SSI absolute encoders.
- Works with incremental encoders.
- Inputs & Outputs:
- Has 12 digital inputs (4 per axis).
- Has 12 digital outputs (4 per axis).
- Inputs sense 24V signals.
- Outputs can handle up to 600 mA.
- Performance & Limits:
- High-speed encoder input: up to 1 MHz.
- SSI encoder cable: up to 300 meters.
- Works from 0°C to 55°C.
- Module weight: 1.3 kg.
Key Benefits For Your Machine
- Precise control for cutting, placing, or moving.
- One module manages three axes, saving cost.
- Easy to set up with Siemens software tools.
- Strong protection against electrical noise.
- Directly powers encoders, simpler wiring.
Package & Warranty Information
- One Siemens FM 451 module (6ES7451-3AL00-0AE0).
- Configuration software CD.
- Full 12-month warranty on all parts.
- Fast shipping via FedEx, UPS, or DHL.
- Technical datasheet included.
Frequently Asked Questions
What kind of motors does this module control?
It sends signals to control servo drives or variable frequency drives (VFDs). It does not power the motor directly.
Can I connect a normal proximity sensor to its input?
Yes. Its 24V digital inputs can connect to sensors, push buttons, or relay contacts.
What is the “flying actual value setting” function?
This lets you update the target position while the axis is still moving. It is useful for conveyor applications.
Is electrical isolation provided for safety?
Yes. The digital inputs and outputs are isolated from the module’s internal logic for protection.
What is a common installation mistake?
Not using shielded cable for encoder wires. This causes noise and false position readings. Always use proper cable.
How To Select This Module
- You have a Siemens S7-400 PLC rack.
- You need to control 1 to 3 axes of motion.
- Your drives accept speed/direction signals.
- You use incremental or SSI absolute encoders.
- Your application needs reliable industrial parts.
