Product Overview
The Siemens 6ES7350-1AH02-0AE0 is an FM 350-1 counter module.
It is designed for SIMATIC S7-300 systems.
The module measures fast encoder signals.
It supports precise motion and speed tasks.
This model is discontinued.
The direct replacement is 6ES7350-1AH03-0AE0.
Main Capabilities
- Counts pulses up to 500 kHz.
- Supports one encoder channel.
- Works with 5V and 24V encoders.
- Handles high-speed position tasks.
- Reduces CPU processing load.
Technical Data
- Manufacturer: Siemens
- Series: SIMATIC S7-300
- Model: 6ES7350-1AH02-0AE0
- Module type: FM 350-1 counter
- Maximum counting frequency: 500 kHz
- Number of channels: 1
- Encoder supply voltage: 5 V or 24 V
- Supported encoder type: Incremental
- Counting modes: Up, down, differential
- Measurement accuracy: High-resolution counting
- Backplane power supply: From S7-300 rack
- Typical power consumption: Approx. 2.5 W
- Net weight: 0.259 kg
- Country of origin: Germany
Lifecycle and Compliance
- Product lifecycle status: Discontinued
- End of lifecycle since October 2011
- Successor model: 6ES7350-1AH03-0AE0
- RoHS compliance: Not compliant
- Export control: No restriction
- Commodity code: 85389091
Installation Notes
- Install into an S7-300 expansion rack.
- Connect encoder signals carefully.
- Use shielded encoder cables.
- Verify signal levels before startup.
Operation and Maintenance
- Configured using Siemens configuration tools.
- Supports stable long-term operation.
- No routine calibration required.
- Replacement recommended during upgrades.
Typical Applications
- Position tracking systems
- Speed measurement tasks
- Packaging machinery
- Conveyors and material handling
- Industrial motion control
Packaging, Warranty, and Shipping
- Packaging size: 13.20 x 15.20 x 5.00 cm
- Packaging quantity: 1 unit
- Warranty period: 12 months
- Shipping via FedEx, UPS, or DHL
FAQ
- Is this module suitable for very fast encoders?
- Yes. It supports counting up to 500 kHz.
- Should I use the successor model instead?
- Yes. 6ES7350-1AH03-0AE0 offers added modes.
- Can this module improve motion accuracy?
- Yes. High-speed counting improves precision.
- Is it compatible with older S7-300 CPUs?
- Yes. It works within supported S7-300 systems.
- When is replacement recommended?
- During system upgrades or encoder changes.
