TC-PMFO01 Honeywell ControlNet Fiber Module for Hazardous Locations
The TC-PMFO01 is a Honeywell ControlNet fiber module built for hazardous locations. It links ControlNet networks over 62.5/125 micron fiber optic cable. The module supports one fiber module plus one repeater adapter module. Power comes through the repeater adapter module. It fits CENELEC II (1) 2G EEx ia/ib IIB/IIC T4 areas. The ST termination accepts plastic or ceramic connectors. The 1300nm wavelength delivers a 13.3dB power budget. Transmission reaches up to 3km (9,842ft) at a 5M bit/s communication rate. Galvanic isolation separates the TTL bus from ControlNet. Use it for long-distance links, noisy plants, and hazardous zones.
Technical Specifications
| Brand | Honeywell |
| Model | TC-PMFO01 |
| Series | ControlNet Fiber Module |
| Module Type | Fiber optic communication module |
| Fiber Module Capacity | 1 Fiber Module plus 1 Repeater Adapter module |
| Input Voltage Rating | Power supplied through Repeater Adapter module |
| Power Consumption | Included with Repeater Adapter module |
| Power Dissipation | Included with Repeater Adapter module |
| Internal Bus (TTL) Output | 30-pin male connector: Uo 5.4Vdc, Io 201mA, Po 1.09W, Lo ≤ 0.45mH, Co 71μF |
| Internal Bus (TTL) Input | 30-pin female connector: Ui 5.4Vdc, Ii 201mA, Pi 1.09W, Li 15μH, Ci 41μF |
| Fiber Optic Type | 62.5/125 micron |
| Fiber Optic Termination | ST (Plastic or Ceramic) |
| Fiber Optic Wavelength | 1300nm |
| Fiber Optic Power Budget | 13.3dB |
| Fiber Optic Transmission Distance | Up to 3kM (9,842ft) |
| Communication Rate | 5M bit/s |
| Galvanic Isolation | Per DIN EN 50 020, TTL Bus / ControlNet |
| Ambient Temperature | –20°C to 70°C (–4°F to 158°F) |
| Storage Temperature | –20°C to 100°C (–4°F to 212°F) |
| Maximum Relative Humidity | 95%, non-condensing |
| Pollution Gas Test | Test Level G3, per ISA-S71.04-1985 |
| Shock Test | 15g peak, 11ms duration |
| Vibration Test | 2g @ 10Hz to 500Hz, per IEC 68-2-6 |
| Protection Class | IP20. Field installation needs a separate housing with IP54 or better. |
| Weight | 0.139 kg (0.31 lb) |
| Dimensions (H x W x D) | 94 x 94 x 87 mm / 3.7 x 3.7 x 3.4 in |
| Conformity to Standards | DIN EN 50014:1992, DIN EN 50020:1997, DIN EN 50284:1997, DIN IEC 721 |
| CE Conformity (Europe) | E.M. Compatibility per DIN EN 50081-2, DIN EN 50082-2, NAMUR NE 21 |
| Classifications | CENELEC (Europe): II (1) 2G EEx ia/ib IIB/IIC T4 |
| Certification | DMT 99 ATEX E 036 X; marked for all applicable directives |
| Measuring Range | Not applicable. This is a communication module. |
| Frequency Response | Not applicable. Data rate is 5M bit/s. |
| Sensitivity | Not applicable. Link margin is 13.3dB. |
| Linearity | Not applicable. Digital fiber link. |
| Resolution | Not applicable. Digital communication at 5M bit/s. |
Installation Guide
- Mount the module in a IP54 or better housing for field use.
- Keep the ambient temperature between –20°C and 70°C.
- Fit the module into the repeater adapter module. Power comes through that adapter.
- Plug the 30-pin male bus connector into the output side.
- Plug the 30-pin female bus connector into the input side.
- Clean the ST connectors before you attach the fiber cable.
- Check the 13.3dB power budget against total link loss.
- Keep fiber bends wide. Do not twist or pinch the cable.
Commissioning and Maintenance
- Verify link status on the ControlNet segment after power-up.
- Measure optical receive power with a fiber meter.
- Re-seat ST connectors if the link drops.
- Inspect connectors for dust during routine service.
- Keep spare adapters on site for fast swap-out.
- Log link margin values to track aging.
Compatibility
- Works with ControlNet networks on 62.5/125 micron fiber.
- Accepts ST plastic or ceramic connectors.
- Pairs with one repeater adapter module for power.
- Fits Honeywell ControlNet systems that use this fiber module family.
Diagnostics
- Link status shows on the host ControlNet segment.
- Optical power readings reveal cable or connector loss.
- A 13.3dB budget check spots weak links early.
- Galvanic isolation blocks ground loops between TTL bus and ControlNet.
Typical Applications
- Long ControlNet runs in hazardous process areas.
- Fiber links across high-voltage or noisy plant sections.
- Repeater links between distant ControlNet segments.
- Chemical, oil and gas, and power plants with ATEX zones.
Certifications
DMT 99 ATEX E 036 X and CENELEC II (1) 2G EEx ia/ib IIB/IIC T4. CE EMC per DIN EN 50081-2, DIN EN 50082-2 and NAMUR NE 21. Standards per DIN EN 50014:1992, DIN EN 50020:1997 and DIN EN 50284:1997.
Packing List and Shipping
- 1 x TC-PMFO01 Fiber Module
- 1 x Repeater Adapter module (power source)
- Protective packaging and anti-static bag
- Shipping by FedEx, UPS or DHL
- 12-month warranty
Why Buy From Oiltech Controls?
- Over 15 years in industrial automation spare parts
- Shipment support worldwide
- Tested surplus and refurbished options
- 12-month warranty
- Technical check before every shipment
- Help with obsolete control systems
FAQ
- Q: Does the module need external power?
A: No. Power comes through the Repeater Adapter module. - Q: What fiber type does it use?
A: 62.5/125 micron multimode fiber. - Q: How far can the link reach?
A: Up to 3km (9,842ft) at 5M bit/s. - Q: What connector type fits?
A: ST plastic or ceramic connectors. - Q: Is it safe for hazardous areas?
A: Yes. It carries CENELEC II (1) 2G EEx ia/ib IIB/IIC T4 classification. - Q: What protection class does it have?
A: IP20. Field use needs an IP54 or better housing. - Q: What is the warranty?
A: 12 months. - Q: How do you ship?
A: By FedEx, UPS or DHL.
