V18345-1010120001 ABB TZIDC Positioner In Stock Fast Shipping V18345

V18345-1010120001 ABB TZIDC Intelligent Electro-Pneumatic Positioner – In Stock – Fast Delivery

The ABB V18345-1010120001 is a high-precision, electronically configurable positioner designed for seamless control of both linear and rotary actuators. This TZIDC series module excels in stable valve positioning via a 4-20 mA two-wire interface. It features an integrated operator panel for instant onsite adjustments and diagnostics.

Technical Specifications

• Manufacturer: ABB
• Model: V18345-1010120001
• Product Type: TZIDC Intelligent Positioner
• Input Signal: 4…20 mA (Two-wire)
• Supply Pressure: 1.4 to 6 bar (20 to 90 psi)
• Air Consumption: < 0.03 kg/h (Ultra-Efficient)
• Output Safety: Single Acting, Fail Safe
• Housing: Aluminum, Protection IP 65 (NEMA 4X)
• Operating Temp: -40 to 85 °C (-40 to 185 °F)
• Air Connections: Thread 1/4-18 NPT
• Electrical Entry: Thread 1/2-14 NPT
• Weight: 1.7 Kg

Configuration Breakdown (Suffix Logic)

• V18345 Series Architecture
  • [1] Case/Mounting: Aluminum, Varnished IP65
    • Linear Actuator (DIN/IEC 534)
    • Rotary Actuator (VDI/VDE 3845)
  • [0] Input/Comm: 4-20 mA with LKS Adapter Plug
  • [0] Explosion Protection: None (Standard Environment)
  • [1] Output/Safe Pos: Single Acting, Fail-Safe Action
  • [2] Connections: 1/2-14 NPT (Elec) / 1/4-18 NPT (Air)
  • [0001] Design/Option: Standard Varnish with Manual Operator Panel

Oiltech Controls Limited’s Insight

From an engineering perspective, the V18345-1010120001 is a benchmark for pneumatic efficiency. The nearly zero steady-state air consumption directly reduces plant energy costs. We highly recommend this TZIDC model for remote sites or facilities where compressor capacity is limited. The V18345-1010120001 offers superior vibration resistance, making it ideal for high-cycling control valves.

Application Scenarios

• Precision control for Globe and Diaphragm valves.
• Quarter-turn Ball and Butterfly valve automation.
• Water treatment chemical dosing loops.
• HVAC steam and chilled water modulation.

Diagnostics & Control Capabilities

• Auto-Calibration: Simple push-button commissioning.
• Travel Limit: Adjustable stroke range between 0 and 100%.
• Travel Time Prolongation: User-defined speeds to prevent water hammer.
• LCD Display: Real-time position tracking and fault code alerts.

Shipping and Warranty

• Fast Dispatch: 12-48 Hours Delivery Guarantee
• Express Carriers: Worldwide shipping via FedEx, UPS, or DHL.
• Condition: Factory New, Original ABB Equipment.
• Warranty: 12-Month Quality Assurance.

Expert FAQ & Selection Guide

• Question: What happens to the valve position if the 4-20mA signal is lost?
  Answer: Since the V18345-1010120001 is a “Fail-Safe” model, the pneumatic output will bleed, allowing the actuator spring to move the valve to its mechanical safe position.
• Question: Is this positioner compatible with M20 conduit threads?
  Answer: No, this specific model (V18345-1010120001) uses 1/2-14 NPT electrical entries. Ensure your conduit fittings match this standard.
• Question: How does the “Shut-off” function protect the valve seat?
  Answer: You can configure a limit (e.g., 1%) where the positioner applies full air pressure to ensure the valve is tightly closed, preventing seat erosion.
• Question: What is the benefit of the LKS adapter plug in this model?
  Answer: It allows for rapid PC-based configuration and diagnostic software connection without opening the main housing.
• Question: Selection Guide: Why choose the NPT connection variant over G threads?
  Answer: The V18345-1010120001 (NPT) is the preferred standard for North American projects and heavy industrial sites using NPT-threaded instrumentation tubing for better sealing in high-pressure environments.
