Product Description
Festo VMPA1-M1H-K-PI is a compact air valve from the MPA-FB-VI Series. It uses a piston slide design for reliable 2×3/2 monostable operation. The valve delivers 230 l/min flow with a 3 to 10 bar pressure range. A soft NBR seal and aluminium housing support clean compressed air control. The 24 VDC electrical actuation and IP65 protection class make it suitable for demanding industrial environments. This valve is a practical choice for factory automation, packaging lines, and obsolete control system support.
Technical Specifications
| Attribute | Value |
|---|---|
| Brand | FESTO |
| Model | VMPA1-M1H-K-PI |
| Series | MPA-FB-VI Series |
| Alternate Mfr Part Number | 533347 |
| UNSPSC Code | 27130000 |
| Valve Type | 2×3/2 Closed, Monostable |
| Actuation | Electrical |
| Coil Voltage | 24 VDC |
| Flow Rate | 230 l/min |
| Operating Pressure | 3 to 10 bar |
| Operating Temperature | -5 to 50 °C |
| Ambient Temperature | -5 to 50 °C |
| Storage Temperature | -20 to 40 °C |
| Fluid Type | Compressed Air |
| Flow Type | Non Reversible |
| Design | Piston Slide |
| Number of Ports | 3 |
| Port Size | 10 mm |
| Mounting Type | Through Hole |
| Housing Material | Aluminium |
| Seal Material | NBR |
| Seal Type | Soft |
| Reset Type | Air Spring |
| Protection Class | IP65 |
| Humidity | 90 %RH |
| Standards | c UL us – Recognized (OL) |
| Shock Resistance | Shock test with severity level 2 in accordance with FN 942017-5 and EN 60068-2-27 |
| Vibration Resistance | Transport application test at severity level 2 in accordance with FN 942017-4 and EN 60068-2-6 |
| Unit of Measure | EA |
Performance and Environmental Tolerance
- Flow Rate: 230 l/min for stable pneumatic control.
- Pressure Range: 3 to 10 bar for broad industrial use.
- Temperature Range: -5 to 50 °C in operation.
- Humidity: Up to 90 %RH with NBR seals.
- Protection: IP65 against dust and water jets.
- Shock and Vibration: Tested to severity level 2 standards.
Installation Guide
- Mount the valve with through-hole fixing.
- Use clean compressed air only.
- Connect a 24 VDC electrical supply.
- Keep port size at 10 mm for correct flow.
- Check pressure stays between 3 and 10 bar.
- Allow enough space for air spring reset.
Commissioning and Maintenance
- Verify coil voltage before power-up.
- Check for leaks at all three ports.
- Replace NBR seals when they wear.
- Keep the valve dry and within temperature limits.
- Inspect the piston slide for contamination.
- Use filtered air to extend service life.
Compatibility Notes
- Works with Festo MPA-FB-VI Series manifolds.
- Fits systems needing 2×3/2 monostable function.
- Alternate part number 533347 aids cross-reference.
- Suitable for obsolete control system replacement.
- Compatible with c UL us recognized setups.
Certification Information
- c UL us – Recognized (OL) for North American use.
- Shock test to FN 942017-5 and EN 60068-2-27.
- Vibration test to FN 942017-4 and EN 60068-2-6.
- IP65 protection class for harsh areas.
Packaging and Warranty
- 1 x Festo VMPA1-M1H-K-PI valve.
- Protective packaging for safe transport.
- 12-month warranty against defects.
- Shipping by FedEx, UPS, or DHL.
- Tracking number provided after dispatch.
Typical Applications
- Factory automation valve islands.
- Packaging and assembly machines.
- Pneumatic clamping and positioning.
- Material handling systems.
- Legacy control panel upgrades.
Diagnostic Capability
- Monostable design gives clear ON/OFF feedback.
- Air spring reset supports predictable return.
- Leak checks at 3 ports speed up fault finding.
- IP65 housing protects internal diagnostics.
- Simple coil test confirms electrical function.
