With armor – 330902-00-12-10-02-00 3300 NSv Proximity Probes

Bently Nevada 330902-00-12-10-02-00 3300 NSv Proximity Probe

Overview

The Bently Nevada 330902-00-12-10-02-00 is a 3300 NSv series proximity probe with a 1/4-28 UNF threaded stainless steel case and armored cable. It is built for precise shaft vibration and position measurements in tight spaces.

Key Technical Specifications

• Measurement Range: 0 to 2 mm (non-contact)
• Accuracy: ±0.07 mm typical
• Output Signal: -200 mV/mil (±5%)
• Power Supply: From Proximitor Sensor
• Operating Temperature: -52°C to +177°C
• Storage Temperature: -52°C to +177°C
• Cable Type: FEP insulated 75 Ω coaxial
• Cable Length: 1.0 meter (39 inches)
• Cable Connector: Miniature coaxial ClickLoc
• DC Resistance: 4.2 ± 0.5 ohms
• Torque Limit: 7.3 N·m max, 5.1 N·m recommended
• Weight: 14 to 150 g
• Pressure Seal: Viton O-ring

Model Code Breakdown

• 330902 = 3300 NSv Series, with armor
• 00 = 0.0 in unthreaded length
• 12 = 1.2 in overall case length
• 10 = 1.0 meter total probe length
• 02 = Miniature coaxial ClickLoc connector, standard cable
• 00 = No agency approval

Installation Guide

• Thread size: 1/4-28 UNF
• Max thread engagement: 0.375 in
• Apply torque: 5.1 N·m (recommended)
• Keep cable bend radius above 25 mm

Compatibility

• Works with 3300 NSv Proximitor Sensors
• Compatible with Bently Nevada 330900 series systems
• Use with 5 mm or smaller shaft targets

Package Includes

• 1x 330902-00-12-10-02-00 Proximity Probe
• Armored cable assembly
• Protective cap
• Warranty: 12 months standard
