With armor – 330902-00-47-10-02-00 3300 NSv Proximity Probes

330902-00-47-10-02-00 | Bently Nevada 3300 NSv Proximity Probe

Product Overview

This 3300 NSv probe (330902-00-47-10-02-00 ) monitors vibration in industrial machines. It has a durable stainless steel case with armor. The probe is built for tough conditions. The cable length is 1.0 meter. It uses a miniature coaxial ClickLoc connector with a standard cable. Made in the USA to ensure high quality.

Model Details

• 330902: Probe with armor
• 00: Unthreaded length 0.0 inch
• 47: Case length 4.7 inches
• 10: Cable length 1.0 meter (39 inches)
• 02: Mini coaxial ClickLoc connector, standard cable
• 00: No agency approval required

Technical Specifications

• Thread size: 1/4-28 UNF
• Probe case material: AISI304 stainless steel
• Probe tip material: Polyphenylene sulfide (PPS)
• Cable type: 75 ohm coaxial with FEP insulation
• Available cable lengths: 0.5, 1, 5, or 7 meters
• Probe weight: 14 to 150 grams (0.5 to 5.3 oz)

Electrical Resistance

• At 1.0 meter cable length: 4.2 ± 0.5 ohms

Torque and Thread Limits

• Recommended torque: 5.1 N·m (45 in·lb)
• Maximum torque: 7.3 N·m (65 in·lb)
• Max thread engagement: 0.375 inches

Temperature Range

• Operating and storage: -52°C to +177°C (-62°F to +351°F)
• Do not expose below -34°C (-30°F) for long time to avoid seal damage

Package Includes

• One 3300 NSv probe with cable

Shipping and Warranty

• Fast shipping by FedEx, UPS, or DHL
• Delivery within 1-3 days
• 12-month warranty included
