With armor – 330902-00-90-10-02-00 3300 NSv Proximity Probes

330902-00-90-10-02-00 3300 NSv Proximity Probe with Armor – Durable and Precise

Model Code Details

• Model: 330902 – NSv probe with 1/4-28 UNF thread and armor
• Unthreaded Length: 00 = 0 in
• Case Length: 90 = 9 in
• Total Length: 10 = 1.0 meter (39 in)
• Connector: 02 = Miniature coaxial ClickLoc connector, standard cable
• Agency Approval: 00 = Not required

Technical Specifications

• Cable: 75 ohm coaxial with FEP insulation
• Cable Length Options: 0.5 m, 1 m, 5 m, 7 m
• Probe Resistance (1 m cable): 4.2 ± 0.5 ohms
• Case Material: Stainless steel AISI 304
• Tip Material: Polyphenylene sulfide (PPS)
• Weight: 14 to 150 grams (depends on cable length)

Installation Guide

• Recommended Torque: 5.1 N·m (45 in·lb)
• Maximum Torque: 7.3 N·m (65 in·lb)
• Maximum Thread Engagement: 0.375 in

Operating Conditions

• Operating Temperature: -52°C to +177°C (-62°F to +351°F)
• Storage Temperature: -52°C to +177°C (-62°F to +351°F)
• Avoid long exposure below -34°C (-30°F) to protect seal

Package Contents

• 1x 330902-00-90-10-02-00 probe with cable and connector
• 12 months warranty
