1606-XLP100F Allen-Bradley Compact DIN Rail PSU, 100 W, 48 V DC Output

1606-XLP100F Allen-Bradley Compact 48 V DC Power Supply, 100 W

1606-XLP100F is a compact switched-mode power supply from the Allen-Bradley Bulletin 1606-XL series. It delivers 48 V DC output at 100 W. The narrow DIN rail housing saves panel space. Spring clamp terminals speed up wiring. A hold-up time above 40 ms at 230 V AC supports short line dips.

This unit suits machine builders, panel integrators and MRO teams. It powers sensors, relays, PLC I/O and small DC loads. The output adjusts from 48 to 56 V. Efficiency reaches 91 percent typical. The design runs cool and keeps losses near 10 W typical.

Technical Specifications

Installation Guide

• Snap the unit onto a standard DIN rail. No tools are needed.
• Keep free space above and below for airflow.
• Use spring clamp terminals for input and output wiring.
• Check input range before power-up. The unit auto-selects AC range.
• Tighten output adjustment only within 48…56 V.
• Respect derating above +60 °C. Load must drop by 2.5 W per °C.

Commissioning and Maintenance

Setup is fast. Set the output voltage, then verify ripple stays below 50 mVpp. The IP20 housing needs no internal cleaning. Check terminal torque at each service interval. Confirm hold-up time after any input change. The unit has no fans, so maintenance stays simple.

Compatibility Notes

The 1606-XLP100F fits Bulletin 1606-XL DIN rail systems. It works with 48 V DC PLC I/O, sensors and relay coils. It has no communication interface. Pair it with standard 48 V DC loads. Do not exceed 2.1 A nominal output.

Diagnostics and Protection

The unit reports status through output behavior. Ripple and noise stay below 50 mVpp in normal use. Overload shows as current limit near 2.1 A. Thermal stress appears above +60 °C. The IP20 rating limits dust and touch access. No digital diagnostics are available.

Typical Applications

• Machine control panels with 48 V DC loads
• PLC I/O and sensor power
• Relay and contactor coils
• Small DC drives and actuators
• Panel retrofits where space is tight

Certifications

Approvals include UL 60950-1, cUL and CE. These follow the official Bulletin 1606 series standard. The IP20 rating and humidity range come from the official product page.

Packing List

• 1 × 1606-XLP100F power supply
• 1 × quick start sheet
• Protective carton with ESD foam

Warranty and Shipping

Every unit carries a 12-month warranty. We ship by FedEx, UPS and DHL. Tracking goes out at dispatch. Global delivery is supported.
