1606-XLS480F-3 Allen-Bradley Performance Power Supply, 48 V DC, 480 W
The 1606-XLS480F-3 is a three-phase performance power supply from the Allen-Bradley Bulletin 1606-XL family. It accepts 380 to 480 V AC three-phase input and delivers 48 V DC at 10 A, giving 480 W. Output adjusts from 48 to 55 V DC. A 50% power reserve covers load peaks. A DC OK relay contact reports supply status to the control system. Spring terminals speed up field wiring. Typical efficiency reaches 95.4%. Rockwell lists the model as active in Bulletin 1606-TD002H (July 2023). Last verified October 2026.
Short Description
Allen-Bradley 1606-XLS480F-3, 480 W, 48 V DC, 10 A, 380 to 480 V AC three-phase. 50% power reserve, DC OK relay, spring terminals, DIN rail mount. 12-month warranty, 24 to 28 hour dispatch, FedEx UPS DHL.
Why Buy From Oiltech Controls?
- Over 15 years of industrial automation spare parts sourcing and application support
- Global shipment support via FedEx, UPS, and DHL
- Tested industrial surplus and refurbished options on selected lines
- 12-month warranty on every unit we supply
- Technical verification before each shipment
- Support for obsolete control systems that remain in service
Electrical Profile
- Model: 1606-XLS480F-3
- Brand: Allen-Bradley
- Series: Bulletin 1606-XL, performance class
- Input voltage: 380 to 480 V AC three-phase nominal
- Output voltage: 48 V DC nominal, adjustable 48 to 55 V DC
- Output current: 10 A nominal, range 10 to 8.7 A
- Rated power: 480 W
- Efficiency: 95.4% typical
- Ripple and noise: 100 mV maximum, 20 Hz to 20 MHz
- Power reserve: 50% for load peaks
Hardware and Mounting
- Mounting: DIN rail
- Connection: spring terminals
- Output adjustment: trim pot
- DC OK relay contact: present
- Dimensions (H×W×D): 124 × 65 × 127 mm
- Weight: 870 g
- Protection rating: IP20, enclosure or DIN rail mount
- Approvals: UL 60950-1, cUL, CE marked
- Built-in ports: none. No communication interface
- Protocols: not applicable to this power supply
Environmental Envelope
- Operating temperature: -25 to +70 °C
- Storage temperature: -40 to +85 °C, non-operating
- Relative humidity: 5 to 95%, non-condensing
- Keep clear of corrosive gas, flammable gas, and heavy dust
- Leave free space above and below the body for convection
Where It Fits
- Three-phase panels needing a 48 V DC bus
- Telecom and radio sites running 48 V equipment
- Drive and servo systems with 48 V control circuits
- Loads with short peaks covered by the 50% reserve
- Spare stock programs for active Bulletin 1606-XLS installs
Oiltech Controls Review
- 95.4% efficiency is excellent for a 480 W three-phase supply. Heat load stays low.
- The 50% reserve handles motor and contactor peaks without a separate buffer.
- Spring terminals speed up wiring. Use ferrules on stranded wire.
- 48 V output suits telecom and drive control loads directly.
- Active status makes this a low-risk spare to hold on the shelf.
Oiltech Controls Insight
- Set output to 48.5 V for long DC runs. It covers cable drop.
- Check all three input phases at the terminal before power-up.
- Wire the DC OK contact to a PLC input for early fault flags.
- The 50% reserve is short-term only. Size continuous loads at 10 A.
- Log the adjusted output voltage on the panel door card.
Warranty and Dispatch
- 12-month warranty on all supplied units
- Dispatch within 24 to 28 hours after order confirmation
- Shipping by FedEx, UPS, and DHL
- Tracking number sent by email after dispatch
- Technical verification before shipment
FAQ
Q: What does the 50% power reserve mean in practice?
A: The unit can deliver short peaks well above 10 A, up to roughly 50% extra. Use it for motor inrush or contactor pull-in. Keep continuous loads at or below 10 A.
Q: Can I run this supply on 400 V AC three-phase?
A: Yes. The input range covers 380 to 480 V AC three-phase. Check phase balance at the terminals before you close the breaker.
Q: How should I set the 48 to 55 V adjustment range?
A: Match your load device input window first. For most 48 V systems, 48.5 V works well. It covers line drop without overstressing the load.
Q: Is the DC OK relay a communication interface?
A: No. It is a dry signal contact only. The supply has no fieldbus or protocol stack. Wire the contact to a PLC input for status.
Q: New or refurbished, which one should I pick?
A: This model is active, so new stock is readily available. Refurbished units suit budget spares. Confirm load test data, DC OK function, and the 12-month warranty before ordering.
