190214-01 Bently Nevada 3500/94M I/O Module | Rear Slot Display Interface

Product Identity

• Manufacturer: Bently Nevada
• Part Number: 190214-01
• Model: 3500/94M Normal I/O Module
• Condition: New and original, factory sealed
• Warranty: 12 months factory coverage

Module Purpose

• Acts as the rear I/O interface for VGA display systems.
• Transfers video, power, and touch signals.
• Supports stable communication with the monitor module.

Input Signal Handling

• Maximum power consumption: 4.6 watts.
• High-speed network receives system status data.
• RS232 port accepts touch controller input.

Output Functions

• VGA output with RGB and sync signals.
• Front port supplies 24 Vdc power.
• Front port outputs VGA and touch commands.

Status Indicators

• OK LED confirms normal module operation.
• TX/RX LED shows active data exchange.

Environmental Tolerance

• Operating temperature: -20°C to 65°C.
• Storage temperature: -40°C to 85°C.
• Humidity up to 95 percent, non-condensing.

Mechanical Profile

• I/O Module Size
  • 241.3 mm × 24.4 mm × 99.1 mm
• Module Weight
  • 0.34 kg

Rack Integration

• Occupies one full-height rear rack slot.
• Designed for direct alignment with monitor module.
• No front-panel access required.

Configuration Breakdown

• 3500/94M
  • Normal I/O Module
    • Standard rear interface configuration
    • Supports VGA, power, and touch signals

Key Product Advantages

• Dedicated design for 3500 display systems.
• Stable signal output under continuous load.
• Compact size reduces rack congestion.
• Factory-tested for reliability.

Logistics and Warranty

• 12-month factory warranty included.
• Shipped in original protective packaging.
• Worldwide delivery via FedEx, UPS, or DHL.

Professional FAQ

• Is this module required for VGA output
• Yes. It provides the physical VGA and power interface.
• Can this module be hot-swapped
• No. Power down the rack before replacement.
• Does it support touch screen input
• Yes. Touch data is received through RS232.
• What should I confirm before ordering
• Check rack type and monitor module version.
• Is this module field repairable
• No. Replacement is recommended if faulty.
