Module Overview
- Manufacturer: Bently Nevada
- Part Number: 3500/94M 190214-02
- Module Type: Power-only I/O Module
- Designed for front-mount display systems.
- Works with 3500/94M display platforms.
- Provides power and signal routing.
- New and original factory packaging.
- Warranty: 12 months.
Configuration Breakdown
- 3500/94M Series
- Display monitoring family
- 190214
- Power-only rear I/O architecture
- Display interface connection module
- 02
- Front display compatible version
- Standard industrial configuration
Core Functional Capabilities
- Supplies stable power to display units.
- Transfers VGA analog signals.
- Supports touch command communication.
- Enables system status monitoring.
- Maintains reliable rack communication.
- Designed for continuous operation.
Electrical Performance
- Maximum Power Consumption: 4.6 W
- Power Output: 24 Vdc front port
- Communication: High-speed internal network
- RS232 Interface: Touch controller data
- Signal Type: Analog RGB + sync
- Stable signal transmission design.
- Low heat generation operation.
Input and Output Interfaces
- OK LED indicates module health.
- TX/RX LED shows communication activity.
- VGA Port outputs video signals.
- Front Port combines power and signal.
- Integrated display communication path.
Environmental Ratings
- Operating Temperature: −20°C to 65°C
- Storage Temperature: −40°C to 85°C
- Humidity: Up to 95% non-condensing
- Designed for industrial cabinets.
- Stable under vibration monitoring environments.
Mechanical Specifications
- Dimensions: 241.3 × 24.4 × 99.1 mm
- Weight: 0.34 kg
- Compact rear-slot installation.
- Space-saving module width.
Rack Installation Requirements
- Requires 1 full-height rear slot.
- Direct integration into 3500 racks.
- No additional adapters required.
- Supports quick replacement maintenance.
Key Product Advantages
- Improves display power stability.
- Reduces wiring complexity.
- Fast communication response.
- Reliable long-term operation.
- Easy installation for engineers.
- Optimized for monitoring systems.
Shipping and Warranty
- Warranty coverage: 12 months.
- Factory sealed packaging.
- Global shipping available.
- Courier options: FedEx, UPS, DHL.
Professional FAQ
- Q: What is the main role of this I/O module?
- A: It powers and connects the display to the rack system.
- Q: Can this module work without a display installed?
- A: No. It is designed specifically for display integration.
- Q: How do engineers confirm compatibility before purchase?
- A: Check rack model and display configuration type.
- Q: Does installation require special tools?
- A: Standard rack installation tools are enough.
- Q: When should users replace this module?
- A: Replace if communication LEDs fail or power output becomes unstable.
