330101-00-40-10-02-05 | Bently Nevada 3300 XL 8 mm Proximity Probe

What This Is

The Bently Nevada 330101-00-40-10-02-05 is an 8mm sensor for machines. It has a 3/8-24 UNF thread and meets explosion safety rules (code 05). Comes with a 1-year warranty.

Part Numbers Explained

• 00: No smooth section
• 40: Body length = 4.0 inches
• 10: Cable = 3.3 feet
• 02: Standard cable + click connector
• 05: Safe for explosive areas

Why It’s Tough

This 3300 XL probe uses double-lock tech to resist 75 lbs pulling. Made with stainless steel body and plastic tip. Optional oil-proof cable available.

Key Numbers

• Power: 7.59Ω ±0.50
• Measure range: 2mm (0.25mm start)
• Error: ±0.025mm
• Wire limit: 1,000 feet

Works In Harsh Conditions

• Temp: -62°F to +350°F
• Humidity: 93% for 56 days
• Seal: Viton ring (not pressure tested)
• Weight: 11.4 oz/m

Support & Safety

This 330101-00-40-10-02-05 follows global safety standards. Add origin certificate if needed. Made in USA. 1-year defect coverage.
