Bently Nevada 330171-00-40-05-02-00 5mm Proximity Probe with 1/4-28 UNF Thread
Description
This Bently Nevada 330171 proximity probe is designed for precise vibration and position monitoring in industrial machinery. The 5mm sensor features a 1/4-28 UNF threaded stainless steel case and a durable PPS probe tip. Ideal for harsh environments, it operates in temperatures from -35°C to +177°C and includes a 0.5m cable with a ClickLoc connector.
Technical Data
- Brand: Bently Nevada
- Model: 330171-00-40-05-02-00
- Probe Type: 5mm, unarmored
- Thread: 1/4-28 UNF (max engagement: 0.375″)
- Case Material: AISI 304 SST
- Tip Material: Polyphenylene sulfide (PPS)
- Unthreaded Length: 0″ (Option 00)
- Case Length: 4.0″ (Option 40)
- Cable Length: 0.5m (Option 05)
- Connector: Miniature coaxial ClickLoc (Option 02)
- Output Resistance: 50Ω
- Power: -17.5Vdc to -26Vdc (12mA max)
- Temperature Range: -35°C to +177°C
- Tensile Strength: 222N (50 lbf)
Installation Guide
For 1/4-28 UNF threading, use a #3 or larger tap drill. Apply 5.1 N·m (45 in·lb) torque to the probe case (max: 7.3 N·m). Maintain a minimum 25.4mm (1.0″) cable bend radius.
Compatibility
Works with Bently Nevada 3300 monitoring systems. Compatible with AISI 4140 steel targets at 1.27mm (50 mils) gap.
Certifications
No agency approvals required (Option 00).
Package & Warranty
- 1x 330171-00-40-05-02-00 Probe
- 12-month warranty
