Bently Nevada 330907-05-30-50-12-05 Reverse Mount Probe
Product Summary
The 330907-05-30-50-12-05 is a 3300 NSv Reverse Mount Probe from Bently Nevada. It features a 5.0-meter cable, M10X1 threads, and a ClickLoc miniature coaxial connector with FluidLoc cable. It is made for high-vibration, high-moisture, or space-constrained industrial setups.
Key Specifications
- Thread Size: M10X1
- Cable Length: 5.0 meters (16.4 feet)
- Connector: Miniature coaxial ClickLoc with FluidLoc cable
- Agency Approvals: 05 = Multiple approvals (CSA, ATEX, IECEx)
- Output Signal: -1 to -13 VDC
- Linear Range: 1.5 mm (60 mils)
- Gap Range: 0.25 mm to 1.75 mm (10 to 70 mils)
- Recommended Gap: 1.0 mm (40 mils)
- Operating Temp: -52°C to +177°C
- Storage Temp: -52°C to +177°C
- Pressure Seal: Viton O-ring
- Weight: 14 to 150 g
Mechanical Details
- Probe Tip Material: Polyphenylene sulfide (PPS)
- Probe Case: AISI 304 stainless steel
- Thread Engagement: 15 mm max
- Torque (Max): 22.6 N·m
- Torque (Recommended): 7.5 N·m
Electrical Properties
- Probe Resistance (1 m cable): 4.2 ± 0.5 ohms
- Wiring Size: 0.2 to 1.5 mm² (16 to 24 AWG)
- Recommended Cable: 3-conductor shielded triad
- Max Field Wiring Length: 305 meters
Model Structure Explained
- 330907: Series and probe type
- 05: Unthreaded length option
- 30: Probe case length option
- 50: Cable length = 5.0 meters
- 12: ClickLoc connector with FluidLoc cable
- 05: Multiple approvals
Installation Tips
- Mount with M10X1 threaded bore
- Use a torque wrench for correct pressure sealing
- Avoid long-term exposure below -34°C to protect seals
