330907-05-30-70-02-05 Bently Nevada | 3300 NSv Reverse Mount Probe

Bently Nevada 330907-05-30-70-02-05 Reverse Mount Probe

Product Overview

This is a reverse mount probe made by Bently Nevada. It is part of the 3300 NSv series. It works well in harsh and dirty places. It is often used in compressors and heavy machines. It has strong resistance to chemicals. The probe connects with a ClickLoc connector to stay secure. The molded tip is strong and will not come loose.

Model Code Breakdown

• 330907: NSv Reverse Mount Probe Series
• 05: Tip Option
• 30: Case Length Option
• 70: Cable Length = 7.0 meters
• 02: Standard coaxial ClickLoc connector
• 05: Approved for multiple safety standards

Build Materials

• Tip: Polyphenylene Sulfide (PPS)
• Case: Stainless Steel AISI 304
• Connector: Brass, gold-plated
• Seal: Viton O-ring
• Weight: 14 to 150 g

Wiring Details

• Wire Size: 16 to 24 AWG (0.2 to 1.5 mm²)
• With Ferrules: 18 to 23 AWG (0.25 to 0.75 mm²)
• Recommended Cable: 3-wire shielded triad
• Max Cable Length: 305 meters

Package Includes

• 1 x Probe (330907-05-30-70-02-05)
• 7.0-meter standard cable
• 12-month warranty

Shipping Options

• FedEx
• UPS
• DHL
