330907-05-30-70-12-05 Bently Nevada | 3300 NSv Reverse Mount Probe

Bently Nevada 330907-05-30-70-12-05 Reverse Mount Probe

Product Overview

The 330907-05-30-70-12-05 is a 3300 NSv reverse mount probe with M10x1 threads. It features a 7.0-meter FluidLoc cable and a miniature ClickLoc connector. It offers better chemical resistance than the 3300 RAM probe, making it ideal for process compressor applications. Its side-view design improves accuracy compared to 3000-series probes.

Model Structure

• 330907 – NSv Reverse Mount Probe Series
• 05 – Unthreaded tip length
• 30 – Probe case length
• 70 – Total length 7.0 meters (23.0 feet)
• 12 – Miniature coaxial ClickLoc connector, FluidLoc cable
• 05 – Multiple Agency Approvals

Technical Specifications

• Measurement Range: 0.25 to 1.75 mm (10 to 70 mils)
• Signal Output: -1 to -13 V DC
• Linear Range: 1.5 mm (60 mils)
• Recommended Gap: 1.0 mm (40 mils)
• Probe DC Resistance: 4.2 ± 0.5 ohms at 1 m
• Max Field Wiring Length: 305 meters (1000 feet)

Temperature Range

• Operating: -52°C to +177°C (-62°F to +351°F)
• Storage: -52°C to +177°C (-62°F to +351°F)
• Warning: Temperatures below -34°C (-30°F) may damage seals

Installation & Wiring

• Wire Size: 0.2 to 1.5 mm² (16 to 24 AWG)
• With Ferrules: 0.25 to 0.75 mm² (18 to 23 AWG)
• Cable Type: 3-conductor shielded triad recommended
