Product Overview
Honeywell 900H03-0202 is a Digital Output Module for 120/240 VAC systems. It provides 8 isolated zero-switching Triac outputs. Each channel has a green LED for ON state. A blinking green status LED shows module scanning. A red status LED shows diagnostics. The module uses MOV protection and a field-replaceable fuse per output. A shorting comb (900J02-0001 or 900J10-0001) helps connect all outputs to a common voltage source. This module fits barrier-type terminal blocks. It supports fail-safe state configuration: Hold Last State or Failsafe State. The design suits industrial automation panels that need reliable AC switching with clear diagnostics.
Technical Specifications
| Brand | Honeywell |
| Model | 900H03-0202 |
| Series | 900H Digital Output |
| Outputs per Module | 8 |
| Output Type | Triac, zero switching voltage |
| Operating Voltage | 85 VAC to 240 VAC |
| Peak Voltage | 250 VAC |
| AC Frequency | 47 Hz to 63 Hz |
| Galvanic Isolation | Per output to output, output to logic |
| ON Voltage Drop | <2.0 VAC (>0.1 A); <3.0 VAC (<0.1 A) |
| Transient Overvoltage Protection | MOV |
| Maximum Load Current | 2 A per point, 8 A max per module (resistive load) |
| Maximum Leakage Current | 4 mA (240 VAC, 60 Hz); 1.2 mA (100 VAC, 60 Hz); 0.9 mA (100 VAC, 50 Hz) |
| Maximum Inrush Current | 15 A for 10 ms |
| Minimum Load | 50 mA |
| OFF to ON Response Time | 3 ms + 0.5-line cycle max (excludes controller scan and backplane transmission) |
| ON to OFF Response Time | 3 ms + 0.5-line cycle max (excludes controller scan and backplane transmission) |
| Fail Safe State | Hold Last State / Failsafe State |
| Fuses | 1 per output, 3.15 A time-lag. Replacement: Littelfuse 37413150410 |
Diagnostics and Maintenance
- Green LED per channel shows output ON state.
- Blinking green status LED shows module scanning.
- Red status LED shows module diagnostics exist.
- Field-replaceable fuse per output simplifies repair.
- MOV transient protection reduces overvoltage risk.
- Fail-safe configuration supports safe shutdown design.
Installation and Compatibility Notes
Use barrier-type terminal blocks with the optional shorting comb 900J02-0001 or 900J10-0001. The comb ties all outputs to a common voltage source. Keep wiring short and use proper AC fusing. The module works with Honeywell 900H series backplane systems. It suits resistive loads within the specified current range. Verify load current stays above 50 mA minimum and below 2 A per point.
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spare parts.
- Global shipment support with FedEx, UPS, and DHL options.
- Tested industrial surplus and refurbished options available.
- 12-month warranty on eligible products.
- Technical verification before shipment to confirm part condition.
- Support for obsolete control systems and legacy Honeywell modules.
Typical Applications
- AC solenoid and valve control in process panels.
- Relay and contactor switching in industrial automation.
- Heater and resistive load banks with zero-switching needs.
- Legacy Honeywell 900H system expansion and replacement.
- Control cabinets requiring per-channel diagnostics and fused outputs.
FAQ
Q: What is the output type?
A: Triac zero-switching, 8 isolated outputs.
Q: What voltage range does it support?
A: 85 VAC to 240 VAC, 47 Hz to 63 Hz.
Q: How much current per point?
A: 2 A per point, 8 A max per module for resistive loads.
Q: What is the minimum load?
A: 50 mA.
Q: How do I check module status?
A: Use the green channel LEDs, blinking green status LED, and red diagnostic LED.
Q: What fuse does it use?
A: 3.15 A time-lag, Littelfuse 37413150410, one per output.
Q: Does it support fail-safe configuration?
A: Yes, Hold Last State or Failsafe State.
