Product Overview
The Honeywell 900P01-0301 is a 120/240VAC power supply built for industrial control systems. It delivers stable output in demanding environments. This module suits legacy and current Honeywell platforms. The design focuses on reliability, simple wiring, and long service life.
Key facts: wide AC input range, high inrush tolerance, internal fuse, and test jacks for quick checks. The unit supports screw terminals for secure field wiring. It is a practical choice for continuous operation in process and factory automation.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | Honeywell |
| Model | 900P01-0301 |
| Series | 900P01 Power Supply Series |
| Product Type | 120/240VAC Power Supply |
| Input Voltage | 90 to 264 V AC, 47 to 63 Hz |
| Input Current | 1.4 A max continuous |
| Inrush Current | 40 A peak-to-peak for 120 ms at 240 V AC |
| Input Rating | 130 VA |
| Output Rating | 58 W |
| Fuse | Internal, non-replaceable |
| Hold-up Time | 20 ms at 115 V AC, 60 Hz, max load |
| Wiring | Screw terminals, 0.3 mm² to 3.3 mm² (#12–22 AWG) |
| Test Jacks | 5 V DC, 24 V DC |
| Dimensions | 137 mm H x 72.6 mm W (5.4 in H x 2.86 in W) |
| Weight | 0.82 kg |
Note: Use the specified wire range. Keep input wiring short to reduce noise. The internal fuse protects the unit. Do not open the housing.
Installation Guide
- Mount the unit on a flat, vibration-free panel.
- Use screw terminals for input and output wiring.
- Tighten screws to a secure torque. Do not over-tighten.
- Keep AC input wires away from signal cables.
- Connect protective earth before power-up.
- Verify input voltage matches the 90–264 V AC range.
- Use the 5 V DC and 24 V DC test jacks for quick checks.
Commissioning and Maintenance
Check output voltage at the test jacks after power-up. The 5 V DC and 24 V DC jacks simplify troubleshooting. No routine calibration is required. Inspect terminals periodically for tightness. Keep the enclosure clean and dry. The internal fuse is not replaceable. Replace the unit if the fuse opens.
Compatibility Notes
This supply fits Honeywell control systems that require a 120/240 VAC input module. It supports 58 W output loads. Confirm your backplane or chassis matches the 900P01 series. The screw terminal layout accepts #12–22 AWG wires. For legacy systems, verify connector pinout before installation.
Diagnostics and Test Points
Front-accessible test jacks provide 5 V DC and 24 V DC readings. Use a calibrated multimeter. Compare readings with system requirements. A missing or low output may indicate input loss, fuse open, or overload. The 20 ms hold-up time helps ride through short AC dips at 115 V AC, 60 Hz, maximum load.
Typical Applications
- Process control systems
- Factory automation panels
- Legacy Honeywell control racks
- Industrial power distribution cabinets
- Continuous-duty control equipment
Why Buy From Oiltech Controls?
- 15+ years of industrial automation spare parts experience.
- Global shipment support by FedEx, UPS, and DHL.
- Tested industrial surplus and refurbished options available.
- 12-month warranty on eligible products.
- Technical verification before shipment.
- Support for obsolete control systems.
Packing List and Warranty
- 1 x Honeywell 900P01-0301 Power Supply
- 1 x Anti-static protective bag
- 1 x Protective carton packaging
- Warranty: 12 months
- Shipping: FedEx, UPS, DHL
Certifications and Compliance
Contact Oiltech Controls for the latest certification documents for this model. We verify labels and condition before dispatch. Documentation support is available for industrial compliance needs.
FAQ
Q: What is the input voltage range?
A: 90 to 264 V AC, 47 to 63 Hz.
Q: Can I replace the fuse?
A: No. The fuse is internal and non-replaceable.
Q: What is the output rating?
A: 58 W.
Q: What test jacks are available?
A: 5 V DC and 24 V DC.
Q: What is the hold-up time?
A: 20 ms at 115 V AC, 60 Hz, maximum load.
