Allen-Bradley DC Input Module – 8-Point SLC 500 Systems | 1746-IV8

Allen-Bradley 1746-IV8: Compact 8-Channel DC Input Module

Monitor DC devices efficiently with the Allen-Bradley 1746-IV8 input module. This space-saving 8-channel module is perfect for SLC 500 systems. The 1746-IV8 accepts sourcing input signals for reliable industrial automation.

Product Overview

The Allen-Bradley 1746-IV8 is a compact DC input module for SLC 500 systems. This 1746-IV8 module features eight sourcing input channels that connect to switches, sensors, and other binary devices. It’s perfect for smaller applications or when you need just a few additional inputs.

Technical Specifications

Brand: Allen-Bradley (Rockwell Automation)
Series: SLC 500
Model: 1746-IV8
Module Type: 8-Point DC Sourcing Input
Input Channels: 8 points, 1 group
Voltage Range: 10-30V DC
Nominal Voltage: 24V DC
Nominal Current: 8 mA at 24V DC
Off-State Voltage: 5V DC maximum
Off-State Current: 1.0 mA maximum
Response Time: 8 ms (ON and OFF)
Backplane Current: 50 mA at 5V DC
Wire Size: 14 AWG (2 mm) recommended
Isolation Voltage: 500V AC for 1 minute
Operating Temperature: 0 to 60°C (32 to 140°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Relative Humidity: 5 to 95% non-condensing
Terminal Type: Removable block
Status Indicators: 8 LED indicators

Warranty & Shipping

All purchases include a 12-month warranty covering defects and performance issues. We ship globally using reliable carriers including FedEx, UPS, and DHL for fast delivery.

Comparison With Similar Products

Consider these alternative input modules for your system:
Allen-Bradley 1746-IB16 (16-Channel DC Sinking Input Module)
Allen-Bradley 1746-IB32 (32-Channel DC Input Module)

Frequently Asked Questions

• What is the difference between sourcing and sinking inputs?
  Sourcing inputs provide voltage to field devices, while sinking inputs receive voltage from field devices.
• How many modules can I install in one chassis?
  The number depends on your processor’s I/O capacity and the number of available slots in your chassis.
• What types of sensors work with this module?
  It works with proximity sensors, push buttons, limit switches, and other DC devices using sourcing configuration.
• Can I use this module in harsh environments?
  Yes, it operates in industrial environments with 5-95% humidity and temperatures from 0-60°C.
• What does the 8ms response time mean?
  The module takes up to 8 milliseconds to detect and report an input state change to the processor.
