Allen-Bradley 1746-OV16: 16-Channel DC Sinking Output Module
Power your industrial automation with the reliable Allen-Bradley 1746-OV16. This robust 16-point output module is designed for SLC 500 systems, delivering high-current control for a wide range of DC devices.
Product Overview
The Allen-Bradley 1746-OV16 is a premium DC sinking output module for SLC 500 PLC systems. This 1746-OV16 module provides sixteen isolated outputs capable of controlling high-current devices like solenoid valves, motor starters, and industrial relays. With its wide operating voltage range and robust construction, it’s ideal for demanding industrial environments.
Technical Specifications
Brand: Allen-Bradley (Rockwell Automation)
Series: SLC 500
Model: 1746-OV16
Module Type: 16-Point DC Sinking Output
Output Channels: 16 points, 1 group
Voltage Range: 10-50V DC
Nominal Voltage: 24V DC
Current per Point (30°C): 0.5 A
Current per Point (60°C): 0.25 A
Total Module Current (30°C): 8.0 A
Surge Current: 3.0 A for 10 ms
On-State Voltage Drop: 1.2 V maximum
Response Time (On to Off): 0.1 ms
Response Time (Off to On): 1.0 ms
Backplane Current: 270 mA at 5V
Heat Dissipation: 7.6 W total
Off-State Leakage: 1 mA maximum
Terminal Type: Removable block
Isolation: 500V AC for 1 minute
