Bently Nevada – 3300 XL 11 mm Extension Cable 330730-080-13-00

Bently Nevada 3300 XL 11mm Armored Extension Cable

Premium triaxial cable for industrial vibration monitoring systems. Features FluidLoc™ leak prevention and military-grade temperature resilience (-51°C to +177°C). Gold-plated ClickLoc® connectors ensure secure connections in critical machinery.

Product Highlights

• 🛡️ Armored construction with AISI 302 SST/FEP jacket
• 💧 FluidLoc technology prevents oil leaks
• 🔒 Patented ClickLoc connectors with 75lb pull strength
• 🌡️ Extreme temperature range: -51°C to +177°C
• 📏 8.0 meter length (26.2 ft)

Technical Specifications

• Brand: Bently Nevada
• Full Model: 330730-080-13-00
• Cable Type: 75Ω triaxial with FEP insulation
• Capacitance: 69.9 pF/m typical
• Resistance: 2.0Ω core-core / 0.6Ω jacket-jacket
• Weight: 140g/m (armored)
• Safety Certification: COO available

Installation Guide

• Use connector protectors in humid environments
• Max field wiring: 305m (1000ft) between sensor & monitor
• Recommended gap setting: 2.5mm (100 mils)
• Compatible thread sizes: ½-20, 5⁄8-18, M14, M16

Package Includes

• 330730-080-13-00 Extension Cable
• Silicone sealing tape
• 12-month warranty

Shipping & Support

• Global delivery via FedEx, UPS, DHL
• Typical applications: Turbine monitoring, compressor vibration analysis, industrial pump diagnostics
• FAQ: Factory calibrated for AISI 4140 steel (other materials on request)

Download Resources

Get installation guides and technical manuals:

• • Download Product Manual (PDF)
