Bently Nevada | 330101-00-30-10-02-05 3300 XL 8 mm Proximity Probe

Bently Nevada 330101 Probe: Key Details

Model 330101-00-30-10-02-05 is a rugged 8mm sensor with a 3.0-inch stainless steel case. Made in USA. Explosion-proof (CSA/ATEX/IECEx). Backed by a 1-year warranty.

Code Breakdown

• -00: Smooth shaft (no threads)
• -30: Case = 3.0 inches
• -10: Cable = 3.3 feet
• -02: ClickLoc connector (easy click)
• -05: Safe for explosive zones

Why Choose 330101-00-30-10-02-05?

• Unbreakable tip: 8mm PPS plastic
• Cable grip: Holds 75 lbs pull force
• Works in extreme temps: -62°F to +425°F
• Stop leaks: Add FluidLock option

Simple Setup Guide

• Use 16-24 gauge wires
• Max distance: 1,000 ft
• Best gap: 1.27mm (50 mils)

Tech Specs Made Clear

• Power use: 7.59Ω ±0.5
• Measures movement: 0.25-2.3mm range
• Humidity proof: 3% max error in wet areas
• Weight: 11.4 oz per foot

Reliability Features

• Stainless steel resists rust
• Seals pressure with Viton® O-ring
• Free COO certificate available
