Bently Nevada 330171-00-20-90-02-00 – 5mm Proximity Probe with 9m Cable
Model Breakdown: 330171-00-20-90-02-00
- 00 = 0″ unthreaded length
- 20 = 2″ case length
- 90 = 9.0m cable
- 02 = Miniature ClickLoc connector
- 00 = No agency approval needed
Technical Specs
- Power: -17.5V to -26V DC, 12mA max
- Output resistance: 50 Ω
- Probe resistance: 9.87 Ω ±0.90
- Max thread engagement: 0.375″
- Weight: 0.323 kg
- Tensile strength: 222N (50 lbf)
- Torque: 5.1 N·m (max 7.3 N·m)
5 FAQ
- Q: Can this probe measure non-metallic targets?
A: No, it’s designed for AISI 4140 steel or similar metals. - Q: Is the cable waterproof?
A: The FEP insulation resists moisture but isn’t fully submersible. - Q: What’s the max voltage for safe operation?
A: Stay between -17.5V to -26V for best performance. - Q: Can I cut the cable to a shorter length?
A: No – cutting voids warranty. Order the correct length. - Q: How do I confirm probe health?
A: Check resistance (center to outer conductor: 9.87Ω ±0.90).
Warranty & Shipping
- 12-month warranty against defects.
- Ships via FedEx, UPS, or DHL worldwide.
