Bently Nevada 330171-08-24-10-02-00 5mm Proximity Probe Module
- Brand: Bently Nevada
- Order Code: 330171-08-24-10-02-00
- Probe Class: 3300 5mm Proximity Probes
- Thread Type: 1/4-28 UNF
- Cable Style: Standard, non armored
- Country: USA
- Main Job: Shaft vibration and gap sensing
Application Focus Snapshot
- Built for rotating equipment
- Best for turbines and compressors
- Good for tight mounting zones
- Supports continuous condition monitoring
- Works in high EMI areas
- Designed for industrial protection systems
Ordering Code Logic Tree
- 330171 Build Map
- 330171 = 5mm eddy current probe head
- 08 = Unthreaded length 0.8 in
- 24 = Case length 2.4 in
- 10 = Cable length 1.0 m
- 02 = Mini ClickLoc connector
- 00 = Standard approval set
Electrical Performance Set
- Supply voltage: −17.5 to −26 Vdc
- Nominal supply: −24 Vdc
- Max current: 12 mA
- Output impedance: 50 ohm
- Supply drift: less than 2 mV per volt
- System gap reference: 1.27 mm
- Target reference: AISI 4140 steel
- Probe DC resistance 1m: 7.59 Ω ±0.50 Ω
- Signal type: analog displacement signal
- Dynamic range: suitable for shaft vibration bands
Physical Build Details
- Tip: PPS high strength polymer
- Case: AISI 304 stainless steel
- Cable: 75 ohm triax FEP
- Connector: Miniature coax ClickLoc
- Connector metal: Gold plated alloy
- Weight: 0.323 kg
Mechanical Limits
- Max thread engagement: 0.375 in
- Install torque best: 5.1 N·m
- Install torque max: 7.3 N·m
- Connector torque max: 0.565 N·m
- Pull strength: 222 N
- Min cable bend: 25.4 mm radius
- Use #3 or larger tap drill
Temperature and Field Tolerance
- Operating range: −35°C to +177°C
- Seal risk below −34°C
- Classification up to +232°C
- T class support from T1 to T5
- Magnetic field tested to 300 Gauss
- Low field induced error
Signal Stability Advantages
- Triax cable blocks external noise
- Stable output near rated gap
- Low temperature drift
- Repeatable readings over time
- Good long term trend quality
Integration Scope
- Fits 5mm Proximity Probes systems
- Pairs with Bently proximitor sensors
- Works with 3300 rack monitors
- Supports standard extension leads
What You Receive
- 1 × 330171 probe
- 1 × Connector protector cap
- 1 × Serial label
- 1 × Inspection mark
Warranty and Delivery
- 12 months warranty
- Functional test before shipping
- Express carriers: FedEx, UPS, DHL
- Worldwide delivery service
Selection Tips
- Choose cable length by cabinet distance
- Match probe size with bracket hole
- Keep same system electrical length
- Check temperature class first
- Use original cable type only
Professional FAQ
- Does case length affect signal quality
- No. It affects mounting depth only.
- When should I pick 1m cable
- Use it for near sensor mounting points.
- How to reduce measurement noise
- Keep cable away from power lines.
- Can I reuse old mounting threads
- Yes, if thread and depth are correct.
- What is a common install mistake
- Too much torque on probe body.
