SCOUT240IS-05 Portable Data Collector
Bently Nevada · Model SCOUT240IS-05 · Intrinsically Safe · 4-Channel Vibration Analyzer
Rugged, lightweight handheld for hazardous areas. ATEX Zone 1 / CSA Class 1 Div 1. Captures vibration, uploads to System 1 for advanced diagnostics. 10-hour battery, IP65, 12,800-line FFT.
Download FRF, Coherence, Modal Impact, Balancing data via Bluetooth or USB.
Key Technical Specifications
| Brand | Bently Nevada |
| Model | SCOUT240IS-05 (Multi Approvals: CSA, IECEx, ATEX) |
| Channels | 4 simultaneous (CH1, CH2, CH3, CH4 via breakout) |
| ADC Resolution | 24-bit |
| Fmax / Lines | 80 kHz / 12,800 lines |
| AC Input Range | 16 V peak-peak (±8 V swing, ±80 g) |
| DC Coupled Ranges | 0–20 V, -10–10 V, -20–0 V |
| Excitation | 0 / 2.2 mA (IEPE/ICP), 24 V max |
| Sensor Support | Accel, Velocity, Displacement, Voltage, AC/DC, Triaxial |
| Balancing | 2 planes, 2 sensors, 3–12,000 RPM |
| Modal / FRF | Coherence, FRF (Accelerance, Mobility, Compliance), UFF export |
| Battery Life | 10 hours (typical) |
| Charge Time | 3 hours (2A nominal) |
| Operating Temp | -20 °C to +60 °C (hazardous: ≤50 °C) |
| Ingress Protection | IP65 (dust/water resistant) |
| Drop Test | MIL-STD-810F, 26 drops @ 1.2 m onto concrete |
| Dimensions | 130 x 130 x 35 mm (5.1 x 5.1 x 1.4 in) |
| Weight | 680 g (1.5 lb) |
| Warranty | 5 years (factory) |
Environmental & Compliance
- Hazardous Area: ATEX Zone 1 / Zone 21, CSA Class 1 Div 1, IECEx
- Charging Ambient: 0 °C to +25 °C (32–77 °F)
- Storage: Short term -20 to +60 °C, 95% RH; Long term 35 °C, 85% RH
- Bluetooth: BT 4.0 Classic (≤101599) / BT 5.0 BLE (≥101600)
- OS Support: Android 5.1–16; iOS 13–17.1.1 (BT 5 BLE required)
- Languages: EN, ZH, FI, DE, JA, RU, ES, TR
Installation, Commissioning & Maintenance
- No mechanical installation — handheld, ready to use.
- Auto sensor detection: bias voltage check, short/open warning.
- Internal battery not user accessible; factory replacement only.
- Charge via 12 V DC, 3 A power pack (included).
- Firmware and app updates via Bluetooth or USB.
Compatibility & Connectivity
- Connectors: 2x LEMO (CH1/CH2), 1x LEMO (Tacho), 1x breakout cable for CH2–4.
- Supports IEPE/ICP, voltage, displacement, and triaxial sensors.
- Data export: UFF, System 1 compatible.
- Works with Modicon Quantum and other PLC/DCS systems via 4–20 mA or voltage output.
- Bluetooth and USB for data transfer.
Diagnostic Capabilities & Typical Applications
- On-route data collection for pumps, fans, compressors, turbines.
- Cross-channel spectrum: 1 reference + 3 sensors, Coherence & FRF.
- Modal impact testing: up to 10 kHz, export UFF for modal/ODS.
- Two-plane balancing up to 12,000 RPM; automatic trial weight removal.
- Detects bearing faults, unbalance, misalignment, looseness.
FAQ – Quick Answers
- Is SCOUT240IS-05 intrinsically safe? Yes, ATEX Zone 1, CSA Class 1 Div 1.
- Can I use it with a triaxial accelerometer? Yes, supports triaxial sensors.
- How long does the battery last? 10 hours typical on-route.
- Does it support balancing? Yes, 2-plane balancing, 3–12,000 RPM.
- What apps are compatible? S1 Collector App for Android/iOS.
Package Contents
- SCOUT240IS-05 Data Collector unit
- CH 2–4 breakout cable
- Shoulder strap with safety breakaway
- Sensor keepers
- 12 V DC, 3 A power pack
- Quick start guide (digital)
