DFE32B SEW PROFINET IO Fieldbus Interface – Gateway Module for MOVIDRIVE
The DFE32B from SEW-EURODRIVE is a PROFINET IO fieldbus gateway module. It links a controller and a drive. It moves data between devices in real time. This module fits the MOVIDRIVE drive family. It is a direct replacement for legacy PROFINET gateway cards. The module name for project planning is MOVIDRIVE DFE32B. The unit draws only 3 W at DC 24 V. It suits panels with tight power budgets. The compact housing measures 0.3 x 5.0 x 3.0 in. Weight is 0.44 kg. The module supports C1 and C2 channels up to 240 bytes each. A 1 s C2 response timeout keeps cyclic traffic stable. The manufacturer code is 10A hex. The profile ID is 0. Index 47 is the supported data set. Slot 0 is the recommended slot number. This listing is for part number MDX61B0008-5A3-4-0T/DER11B/DFE32B (18213456).
Technical Specifications
| Brand | SEW-EURODRIVE |
| Model | DFE32B |
| Series | MOVIDRIVE gateway modules |
| Module type | PROFINET IO fieldbus interface |
| Product number | DFE32B |
| Part number | MDX61B0008-5A3-4-0T/DER11B/DFE32B (18213456) |
| Function | Controller to drive communication, real-time data exchange |
| Power consumption | P = 3 W |
| Voltage supply | U = DC 24 V (-15 %, +20 %) |
| Dimensions | 0.3 x 5.0 x 3.0 in (0.6 x 12.7 x 7.6 cm) |
| Weight | 0.44 kg |
| Max. C1 channel length | 240 bytes |
| Max. C2 channel length | 240 bytes |
| C2 response timeout | 1 s |
| Supported data set | Index 47 |
| Recommended slot | 0 |
| Manufacturer code | 10A hex (SEW-EURODRIVE) |
| Profile ID | 0 |
| Module name for project planning | MOVIDRIVE DFE32B |
Note on measured ratings: this gateway carries no analog measurement range, frequency response, sensitivity, linearity or resolution figures. It is a digital bus interface. Its relevant ratings are bus capacity, timeout and supply tolerance.
- Temperature range: confirm cabinet ambient limits in the MOVIDRIVE system manual.
- Environmental tolerance: designed for dry, filtered industrial control cabinets.
- Noise immunity: supports shielded PROFINET cabling and standard EMC bonding.
- Bus isolation: keeps drive-side noise off the network segment.
Installation Guide
- Power down the drive and the cabinet before you start.
- Set the slot number to 0 in the project tool.
- Insert the module into the MOVIDRIVE option slot.
- Tighten the retaining screws by hand.
- Connect DC 24 V and check polarity.
- Use shielded PROFINET cable. Keep bends wide.
- Bond the shield to the cabinet ground bar.
- Import the GSDML file and set the module name to MOVIDRIVE DFE32B.
- Assign Index 47 as the data set.
Commissioning and Maintenance
- Confirm the 10A hex manufacturer code after boot.
- Check that C1 and C2 channels map inside 240 bytes.
- Watch the first cycles for timeout events near 1 s.
- Log the supply voltage at the terminal under load.
- No routine service parts are needed. Keep the fan filter clean.
- Reseat the module if the network drops after transport.
Compatibility Notes
The DFE32B pairs with MOVIDRIVE B drives. The reference assembly is MDX61B0008-5A3-4-0T with DER11B and DFE32B. It speaks PROFINET IO with profile ID 0. It replaces earlier PROFINET gateway cards in the same slot. Check your GSDML version before you swap hardware. Confirm firmware level in the drive parameter tree. Mixed fleets with other fieldbuses need a separate gateway. Contact us with your drive nameplate for a fit check.
Diagnostics Capability
- Link and activity LEDs show bus state at a glance.
- The controller reads module status over PROFINET.
- Timeout counters expose weak cabling.
- Channel length checks catch oversized C1 or C2 mapping.
- Supply alarms show brownout risk on the 24 V rail.
- Name mismatch shows as a startup fault in the project tool.
Typical Applications
- Packaging lines with MOVIDRIVE B drives.
- Material handling conveyors on PROFINET.
- Retrofits of legacy SEW gateway cards.
- Assembly cells that need fast cyclic drive data.
- Food and beverage lines with shielded cabinets.
- Obsolete control systems kept in service.
