Product Overview
SICK DT50-P2123 is a high-performance industrial distance sensor. It belongs to the Dx50 DT50 Hi series. This sensor uses HDDM™ optical time-of-flight technology. It measures natural objects up to 13 meters. The laser is Class 1 eye-safe. It offers repeatability ≥ 1 mm. The housing is zinc die-cast for heavy-duty use. A clear LC display and buttons make setup easy. This sensor works in temperatures from -30 °C to +65 °C. You can extend it with cooling plates. It is ideal for tough automation tasks.
Technical Specifications
| Brand | SICK |
| Model | DT50-P2123 |
| Series | Dx50 / DT50 Hi |
| Part Number | 1047399 |
| Measurement Principle | HDDM™ Optical Time-of-Flight |
| Measuring Range | 200 mm … 13,000 mm (90% remission) 200 mm … 5,800 mm (18%) 200 mm … 3,400 mm (6%) |
| Light Source | Red laser diode, 658 nm, Class 1 |
| Laser Class | Class 1 (IEC 60825-1:2014, EN 60825-1:2014) |
| Response Time | Fast: 15 ms / Medium: 30 ms / Slow: 80 ms |
| Repeatability | ≥ 1 mm |
| Accuracy | Typ. ± 7 mm |
| Output Interface | 1x PNP (≤ 100 mA); 1x analog 4–20 mA (≤ 300 Ω, 16-bit); 1x MF input |
| Supply Voltage | DC 10 V … 30 V (reverse-polarity protected) |
| Power Consumption | ≤ 2.1 W (no external load) |
| Electrical Connection | M12, 5-pin male connector |
| Operating Temperature | -30 °C … +65 °C (standard) -30 °C … +80 °C with 2 cooling plates -30 °C … +140 °C with 2 cooling plates + filter |
| Storage Temperature | -40 °C … +75 °C |
| Protection Rating | IP65 (EN 60529) |
| Dimensions (WxHxD) | 36.1 mm x 62.7 mm x 57.7 mm |
| Housing Material | Zinc die-cast (ZNAL4CU1), PMMA window |
| Weight | Approx. 200 g |
Key Features
- Direct diffuse measurement up to 13 m on natural objects
- Eye-safe Class 1 laser with high repeatability
- Rugged zinc die-cast housing for heavy-duty automation
- High-resolution LC display and intuitive menu buttons
- HDDM™ technology for ambient light stability
- Cooling plate expansion up to +140 °C
Installation Guide
Mount the sensor using the M12 5-pin connector. Keep the optical window clean. Align the laser to the target. Use the LC display for quick setup. For high-temperature areas, add cooling plates. The IP65 rating allows use in dusty or wet environments. Do not exceed 30 V DC. Connect PNP or analog output as needed. The multifunctional input (MF) can trigger or teach settings.
Setup and Maintenance
Use the menu buttons to set response time and output. Choose Fast (15 ms), Medium (30 ms), or Slow (80 ms). The LC display shows distance and status. Clean the PMMA window with a soft cloth. Check the connector for tightness. No regular calibration is needed. The HDDM™ design resists ambient light interference. For harsh conditions, add the protection filter (sold separately).
Compatibility
The DT50-P2123 works with standard M12 5-pin cables. It supports PNP digital output and 4–20 mA analog output. The multifunctional input accepts standard PLC signals. It is compatible with SICK mounting brackets and cooling plates. The sensor fits into existing Dx50 series installations. It can replace older Dx50 models with similar wiring.
Certifications
- IEC 60825-1:2014 (Laser Class 1)
- EN 60825-1:2014 (Laser Class 1)
- EN 60529 (IP65)
- CE compliant
Package Contents
- 1x SICK DT50-P2123 sensor
- 1x Quick start guide
- 1x Declaration of conformity
Note: Cables and mounting brackets are not included. Order separately.
Warranty and Shipping
All products come with a 12-month warranty. We ship via FedEx, UPS, and DHL. Tracking is provided. Orders ship within 1–2 business days after verification.
Typical Applications
- Automated guided vehicles (AGVs) for collision avoidance
- Logistics sorting on conveyors
- Steel and metal processing for position control
- Robotics for distance sensing
- Overhead cranes for anti-sway systems
- Material handling in dusty or outdoor areas
Diagnostic Capabilities
The LC display shows live distance and error codes. The multifunctional input can trigger self-test. The sensor reports weak signal or out-of-range via output. You can read status through the analog current. The HDDM™ system monitors ambient light and adjusts. This helps with predictive maintenance.
Why Buy From Oiltech Controls?
- 15+ years of industrial automation spare parts experience
- Global shipment support with FedEx, UPS, and DHL
- Tested industrial surplus and refurbished options
- 12-month warranty on every unit
- Technical verification before shipment
- Support for obsolete control systems
Contact us for inquiries: info@oiltechcontrols.com or +86 158 8020 0923 (WhatsApp).
FAQ
Q: What is the maximum measuring distance?
A: Up to 13,000 mm on 90% remission targets.
Q: Is the laser eye-safe?
A: Yes, it is Class 1 per IEC 60825-1:2014.
Q: Can it work in high temperatures?
A: Standard range is -30 °C to +65 °C. With cooling plates, up to +140 °C.
Q: What output types are available?
A: PNP digital and 4–20 mA analog.
Q: Does it come with a warranty?
A: Yes, 12-month warranty from Oiltech Controls.
Q: How fast is shipping?
A: We ship via FedEx, UPS, DHL. Orders leave in 1–2 days.
