GE IS230SNTCH2A Rev A Thermocouple Input Module | Mark VIe

IS230SNTCH2A Rev A Thermocouple Input Module – GE Mark VIe

This simplex input module reads thermocouple sensors directly. It converts low-level voltage signals into digital data for turbine control. The module ensures precise temperature tracking under extreme conditions.

Technical Specifications

Installation & Commissioning

• Mount the module in a Mark VIe rack. Use the recommended slot.
• Connect thermocouple leads to the terminal block. Follow polarity markings.
• Use shielded cables for long runs. Ground the shield at one end only.
• Power up the rack. The module auto-initialises in 2 seconds.
• Check LED status: green means normal, red indicates fault.

Debugging & Maintenance

• Diagnostic LED shows channel status and communication errors.
• Use ToolboxST software to read live data and configure alarms.
• Hot-swap support: replace the module without shutting down the system.
• Firmware updates via the backplane. No special tools required.
• Routine check: clean the connector pins with isopropyl alcohol.

Compatibility

• Works with all Mark VIe controllers and I/O racks.
• Supports thermocouple types: J, K, T, E, R, S, B, N.
• Fully compatible with GE’s ToolboxST and CIMPLICITY.
• Interfaces with Modicon Quantum via gateway (not direct).
• Backward compatible with earlier Mark VI versions.

Certifications

• UL 508 Industrial Control Equipment
• CE marked (EN 61326-1)
• RoHS compliant
• ATEX for hazardous areas (Group II, Category 3)
• ISO 9001:2015 manufacturing

Package Contents

• IS230SNTCH2A Rev A module (1 unit)
• Terminal block connector (pre-wired)
• Documentation CD (user manual & datasheet)
• Mounting screws and grounding strap
• Warranty card (12 months)

Shipping & Delivery

• FedEx – priority worldwide (2–4 business days)
• UPS – express and economy options
• DHL – international door-to-door tracking
• All shipments include insurance and real-time tracking.

Typical Applications

• Gas and steam turbine bearing temperature monitoring
• Combustion chamber overheat protection
• Exhaust gas temperature measurement
• Compressor inlet/outlet temperature sensing
• Generator winding and cooling air temperature

Diagnostic Capabilities

• Open-circuit detection for each channel
• Short-circuit and over-range alarms
• Cold-junction compensation monitoring
• Status register provides fault history
• Self-test routine on power-up

FAQ – Quick Answers

Q: Can I mix thermocouple types on one module?
A: Yes, but each channel must be configured individually in software.

Q: What is the update rate per channel?
A: 250 ms for all 16 channels simultaneously.

Q: Does this module support HART protocol?
A: No, it is a pure thermocouple input module without HART.

Q: Is calibration required after installation?
A: Factory-calibrated. Re-calibrate every 2 years for critical applications.

Q: What happens if the ambient temperature exceeds 70 °C?
A: The module may shut down or give inaccurate readings.

Why Buy From Oiltech Controls?

• Over 15 years of experience in industrial automation spares.
• Global shipping with FedEx, UPS, and DHL.
• Every unit is tested and verified before dispatch.
• We offer surplus and refurbished options – all fully functional.
• 12-month warranty for peace of mind.
• Technical support for obsolete systems – we know the legacy.

Contact Information
Email: info@oiltechcontrols.com
WhatsApp: +86 158 8020 0923

For integration with Modicon Quantum systems, refer to Modicon Quantum Series.
