GT2-71MCP Keyence Digital Contact Sensor Amplifier Unit
GT2-71MCP is a high-accuracy digital contact sensor amplifier unit from the Keyence GT2 series. It mounts on a DIN rail as a multi-head main unit. The unit delivers a 0.1 µm display resolution for precise position and thickness checks. It supports PNP open collector outputs and a 4 to 20 mA analog output. Use it with optional GT2 communication units for network expansion. This amplifier suits inline measurement, fixture monitoring, and automated inspection stations.
Technical Specifications
| Brand | Keyence |
| Model | GT2-71MCP |
| Series | GT2 series |
| Module Type | High-accuracy digital contact sensor amplifier unit |
| Mounting | DIN-rail mount, multi-head main unit |
| Display Range | -199.999.9 to 199.999.9 |
| Display Resolution | 0.1 µm |
| Response Time | hsp(3)/5/10/100/500/1,000 ms. hsp(12)/20/40/400/2,000/4,000 ms with GT2-Pxxx heads |
| Control Input | Timing, preset, reset, bank no-voltage input |
| Built-in Ports | None |
| Protocols | None |
| Communication Expansion | Via optional GT2 series communication units, sold separately |
| Supply Voltage | 10 to 30 VDC, ripple p-p 10 percent included, Class 2 |
| Power Consumption | 2,700 mW or less. 90.0 mA or less at 30 V |
| Output Type | HH/HI/GO/LO/LL PNP open collector. 40 V / 50 mA or less. Residual voltage 1 V or less |
| Analog Output | 4 to 20 mA. Max load resistance 350 Ω |
| Operating Temperature | -10 to +50 °C, no freezing |
| Relative Humidity | 35 to 85 % RH, no condensation |
| Weight | Approx. 140 g, including power cable |
| Lifecycle | Active. Official Keyence production status confirmed. Last verified: 2026-09 |
Measurement Range and Resolution
- Display range: -199.999.9 to 199.999.9
- Display resolution: 0.1 µm for fine measurement tasks
- Response time: Selectable from 3 ms to 4,000 ms depending on head type
- Frequency response: Fast hsp mode supports high-speed sampling
- Linearity and sensitivity: Maintained through Keyence GT2 sensor heads
Environmental Tolerance and Noise Immunity
The GT2-71MCP operates from -10 to +50 °C without freezing. It handles 35 to 85 % RH without condensation. The PNP output design supports stable switching in industrial panels. The analog output uses a 4 to 20 mA loop for noise-resistant signal transmission. Use shielded cables and a clean 24 VDC supply for best results.
Installation Guide
- Mount the unit on a standard DIN rail inside a control cabinet.
- Connect a 10 to 30 VDC Class 2 power supply.
- Wire the PNP open collector outputs to the PLC or indicator.
- Connect the 4 to 20 mA analog output to a 350 Ω or lower load.
- Attach GT2 series sensor heads and optional communication units.
- Keep signal cables away from high-voltage motor lines.
Commissioning and Maintenance
Set the response time to match your cycle. Use timing, preset, reset, and bank inputs for fast changeover. The digital display shows live values for quick setup. Clean the display and terminals with a dry cloth. Check DIN rail clips and cable strain relief during scheduled maintenance. No internal calibration is required under normal use.
Compatibility Notes
- Works with Keyence GT2 series sensor heads.
- Supports GT2-Pxxx heads with slower response time settings.
- Expands via optional GT2 communication units.
- PNP outputs match common industrial PLC inputs.
- Analog 4 to 20 mA output fits data loggers and panel meters.
Certifications and Warranty
Official Keyence product status is Active. Certification details follow the original manufacturer label. Oiltech Controls supplies a 12-month warranty on this item. Each unit undergoes technical verification before shipment.
Packing List
- 1 x Keyence GT2-71MCP amplifier unit
- 1 x power cable
- Protective packing and anti-static wrap
- Order and test documentation
Shipping Methods
We ship by FedEx, UPS, and DHL. Tracking is provided after dispatch. Contact info@oiltechcontrols.com or +86 158 8020 0923 for urgent orders.
Typical Applications
- Inline thickness and height measurement
- Fixture and gap verification
- Automated assembly inspection
- Position feedback on production machines
- Obsolete control system replacement
Diagnostic Capabilities
The digital display helps diagnose sensor head alignment. HH, HI, GO, LO, and LL outputs show pass and fail states. The 4 to 20 mA analog signal supports trend monitoring. Bank input allows fast recipe switching. These features reduce downtime during setup and troubleshooting.
FAQ
Q: Does the GT2-71MCP have built-in communication ports?
A: No. It needs optional GT2 series communication units.
Q: What is the display resolution?
A: The display resolution is 0.1 µm.
Q: What output type does it use?
A: It uses HH/HI/GO/LO/LL PNP open collector outputs.
Q: What is the analog output?
A: The analog output is 4 to 20 mA with a max load of 350 Ω.
Q: What is the operating temperature?
A: The operating temperature is -10 to +50 °C without freezing.
Q: What is the warranty?
A: Oiltech Controls offers a 12-month warranty.
