GE Fanuc IC695CEP001 PROFINET CEP Carrier for RX3i Systems

The IC695CEP001 from GE Fanuc serves as a advanced communication backbone for PACSystems RX3i platforms. This robust CEP carrier delivers seamless PROFINET integration with dual Ethernet ports and comprehensive I/O management. It ensures reliable data exchange and network connectivity for industrial automation applications.

Technical Specifications & Performance Data

• Brand: GE Fanuc
• Model: IC695CEP001
• Input Voltage: 19.2-30V DC
• Power Consumption: 5.25W @ 24V DC
• Network Protocol: PROFINET 2.3 (Class A)
• Data Throughput: 1024 bytes/station
• Input Data Capacity: 512 bytes
• Output Data Capacity: 512 bytes
• Status Monitoring: 32 input status bits
• Control Capacity: 32 output control bits

Connectivity & Interface Details

• The module features two 10/100 Base-TX Ethernet ports for network connectivity
• It includes a Micro-B USB 2.0 port for firmware maintenance
• This carrier supports single I/O module integration per station
• Physical Dimensions: 177.2 × 51 × 35 mm
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5% to 95% non-condensing

System Integration & Compatibility

• The IC695CEP001 requires Proficy Machine Edition 8.0 SIM 5 or newer
• It enables advanced remote node scanning capabilities
• The module supports multiple network topology configurations
• It provides enhanced diagnostic and fault handling features
• This component operates on high-speed I/O LAN infrastructure

Packaging & Shipping Details

• Each package contains one IC695CEP001 CEP Carrier Module
• All shipments include comprehensive installation documentation
• We provide 12-month product warranty coverage
• Global shipping via FedEx, UPS, and DHL available

Comparison with Complementary Products

• The IC695CEP001 focuses on PROFINET communication functions
• For power backup solutions, consider the IC695ACC403 Energy Pack
• The IC695ACC412 provides capacitor-based power support

Professional FAQ Section

• What network redundancy features does this carrier support?
• The dual Ethernet ports enable network redundancy configurations for increased reliability.
• Can I use this module in harsh industrial environments?
• Yes, it operates reliably across wide temperature ranges from 0°C to 60°C.
• What is the maximum cable length for Ethernet connections?
• Standard Ethernet cabling up to 100 meters works with both RJ-45 ports.
• How do I update the firmware on this PROFINET carrier?
• Use the Micro-B USB port with Proficy Machine Edition for firmware updates.
• What diagnostic capabilities does this module provide?
• It offers comprehensive status monitoring through 32 input status bits.
