Product Summary
The GE Fanuc Emerson IC754VSL06CTD is a compact QuickPanel Plus HMI built for clear machine control and modern automation tasks.
Design & Display
- 6 inch widescreen color display.
- WVGA resolution of 800 x 480 pixels.
- LED backlit TFT panel.
- Clear view in industrial lighting.
Touchscreen Technology
- Projected capacitive touch interface.
- Fast and smooth touch response.
- Supports multi-touch gestures.
- Easy cleaning surface.
Processing & Memory
- ARM Cortex A8 processor at 1 GHz.
- 512 MB RAM for smooth operation.
- 512 KB SRAM with battery backup.
- 256 MB internal ROM storage.
Operating System & Software
- Windows 7 Embedded Compact OS.
- Supports Proficy View Machine Edition.
- Stable platform for HMI projects.
Communication Interfaces
- RS232 and RS485 serial ports.
- USB and Ethernet connectors.
- SD card slot for data transfer.
- Uses HMI-CAB-CS1 cable.
Power & Electrical Data
- Input power range from 12 to 30 VDC.
- Typical operation at 24 VDC.
- Maximum power use of 15 watts.
- Wide tolerance improves stability.
Mechanical & Protection
- IP65 rated front enclosure.
- Dimensions: 7.56 x 5.39 x 1.42 inches.
- Compact size fits small panels.
- Net weight: 2.06 lbs.
Environmental Limits
- Operating temperature from 0 to 50 °C.
- Designed for indoor industrial use.
- Stable operation in control cabinets.
Typical Use Cases
- Compact machine control.
- Packaging and labeling systems.
- OEM automation equipment.
- Local operator stations.
Key Benefits
- Small size with strong performance.
- Modern touchscreen experience.
- Flexible power input range.
- Easy system integration.
Warranty & Shipping
- 12 month warranty included.
- Tested before shipment.
- FedEx worldwide delivery.
- UPS and DHL options available.
Professional FAQ
- Is this HMI suitable for small machines?
- Yes. Its size fits compact control panels.
- Can programs be loaded without a PC?
- Yes. Use an SD card for program transfer.
- Is this panel power flexible?
- Yes. It supports a wide DC voltage range.
- How do I choose between 6 inch and larger panels?
- Select based on screen space needs.
- Does this model support future expansion?
- Yes. Ethernet and USB allow growth.
