MC07B0055-5A3-4-00 SEW MOVITRAC B Inverter, 5.5 kW
The MC07B0055-5A3-4-00 is a MOVITRAC B frequency inverter from SEW. It drives a 5.5 kW / 7.4 HP motor from a 3-phase 380–500 V supply. Output is 12.5 A, 0–500 V, 0–180 Hz. The size 2S housing measures 105 × 335 × 238 mm and weighs 5 kg. Rated ambient is 0 to 50 °C, protection IP20. The drive fits panel builds that need a small footprint and a wide voltage window.
Why Buy From Oiltech Controls?
- Over 15 years sourcing automation spares worldwide
- Worldwide dispatch through established freight partners
- Bench-tested surplus and refurbished stock
- 12-month warranty on every shipped unit
- Function check before the box leaves our warehouse
- Legacy drive and control system support
Technical Data
- Brand: SEW-Eurodrive
- Model: MC07B0055-5A3-4-00
- Series: MOVITRAC B
- Type: Frequency inverter drive, 3-phase
- Input: 11.3 A, 380–500 V ±10%, 50/60 Hz ±5%
- Output: 12.5 A, 0–500 V, 0–180 Hz
- Motor power: 5.5 kW / 7.5 HP
- Size: 2S, 105 × 335 × 238 mm
- Weight: 5 kg
- Ambient: 0 to 50 °C
- Protection: IP20
What This Drive Suits
- Conveyor and transport sections with variable speed
- Pumps and fans with soft-start demand
- Packaging and filling lines
- Retrofit of cabinets with 400 V three-phase rails
- Machines that need 0–180 Hz field weakening range
Oiltech Controls Review
- We check input and output stages before dispatch.
- We record firmware and parameter state where possible.
- We confirm the rating against your motor nameplate.
- We ship by FedEx, UPS, or DHL.
- Orders leave in 24–28 hours after payment clears.
Warranty and Dispatch
- 12-month warranty from delivery date
- Dispatch in 24–28 hours
- Couriers: FedEx, UPS, DHL
- Tracking number sent on shipping
FAQ
Q: The nameplate says 7.5 HP but the sheet says 7.4 HP. Which is right?
A: Both. 5.5 kW converts to 7.4 HP. SEW also markets this frame as 7.5 HP. Match the kW and the 12.5 A output current to your motor, not the HP label.
Q: Can I run this on a 480 V plant supply?
A: Yes. The input range is 380–500 V ±10%. Set the motor data to your actual line voltage. Check the motor insulation class first.
Q: Is IP20 enough for a washdown area?
A: No. IP20 is for clean panel mounting. For wet or dusty rooms, fit a sealed enclosure with proper heat removal.
Q: Do you supply the parameter list with the unit?
A: We include a test report. For a full parameter set, send us the machine type and we will guide the setup.
Q: How do I pick between this and a smaller MOVITRAC B frame?
A: Check motor current first. If your motor draws near 12.5 A, take this 2S frame. For short duty below 1.6 A, a size 0XS unit is cheaper and smaller.
