Product Overview
The Vibro-Meter CP 216 offers stable dynamic pressure sensing for harsh and high-temperature environments.
Technical Specifications
- Brand: Vibro-Meter, Model: CP 216, Ordering No. 143-216-000-031.
- Sensitivity: 200 pC/bar.
- Range: 0.0005–250 bar, Spike limit 350 bar.
- Frequency: 2 Hz–15 kHz.
- Resonant frequency: > 80 kHz.
- Linearity: ±1%.
- Acceleration sensitivity: 0.5 pC/g.
- Capacitance: 320 pF + 200 pF/m cable.
- Temp range: -54 to 470°C, extreme -70 to 520°C.
- Connector temp: up to 650°C (high-temp type).
- Housing: NIMONIC® 90; Cable: INCONEL® 600.
- Calibration at 1 bar, 2 Hz.
- Weight: Transducer 12 g, Cable 25 g/m.
Installation Guide
- Install on a stable port with clean contact surfaces.
- Route MI cable with smooth curves.
- Use a charge converter or IPC 704 conditioner.
- Check connector temperature limits.
- Verify zero after installation.
Package Contents
- One Vibro-Meter CP 216 sensor.
- One LEMO or high-temperature connector.
- One calibration sheet.
- One installation guide.
- Shipping via FedEx, UPS, or DHL.
Applications
- Gas turbines and heavy-duty engines.
- High-temperature test stands.
- Dynamic pressure monitoring.
- R&D environments with extreme heat.
- Areas requiring stable long-term sensing.
FAQ
- Q: What is the pressure range?
A: It measures 0.0005–250 bar with spikes to 350 bar. - Q: What is the frequency range?
A: It covers 2 Hz–15 kHz. - Q: Which connector suits high heat?
A: Use the Vibro-Meter high-temperature connector up to 650°C.
