330172-00-12-05-02-00 | Bently Nevada 5mm Proximity Probe

Bently Nevada 330172-00-12-05-02-00 – 5mm Armored Proximity Probe

Model Breakdown (330172-00-12-05-02-00)

• 330172 – Base model (5mm armored probe)
• 00 – Unthreaded length: 0 in
• 12 – Case length: 12 in
• 05 – Cable length: 0.5m (1.6 ft)
• 02 – Connector: Miniature Coaxial ClickLoc
• 00 – No agency approval required

Technical Specifications

• Voltage Range: -17.5V to -26V DC
• Current Draw: ≤12mA
• Output Resistance: 50Ω
• Probe Resistance: 7.45Ω ±0.50
• Max Thread Engagement: 0.375 in
• Recommended Torque: 5.1 N·m (45 in-lb)
• Weight: 0.323 kg

Installation Notes

• Use #3 or larger tap drill for mounting
• Do not exceed 7.3 N·m (65 in-lb) torque
• Minimum cable bend: 25.4mm (1.0 in)

FAQ

• Can this probe measure non-ferrous metals? No, optimized for AISI 4140 steel.
• Is the cable replaceable? No, it’s permanently attached.
• What’s the difference between armored/unarmored? Armored probes have extra cable protection.
• Can I use this in underwater applications? No, not submersible-rated.
• How do I confirm proper gap distance? Use a 1.27mm (50 mil) spacer during setup.

Shipping & Warranty

• Fast global shipping via FedEx, UPS, or DHL
• 12-month warranty against defects
