330172-00-40-05-02-00 | Bently Nevada 5mm Proximity Probe

Bently Nevada 330172-00-40-05-02-00 Heavy-Duty Armored Vibration Probe

Built for Industrial Toughness

• 🏭 4.0″ armored length for maximum protection
• ⚡ Precision 5mm sensing with PPS tip
• 🔧 1/4-28 UNF threaded for secure mounting
• 🌡️ Wide temperature range (-35°C to +177°C)
• 🇺🇸 Made in USA quality

Model Number Explained

Key Performance Specs

• Power Input: -17.5V to -26V DC
• Current Draw: 12mA max
• Output Resistance: 50Ω
• Probe Resistance: 7.45Ω ±0.50
• Cable Type: 75Ω triaxial FEP
• Weight: 0.323kg
• Installation Torque: 5.1-7.3 N·m

Common Technical Questions

• Q: Why choose 4.0″ armored length?
  A: Provides extra protection in high-vibration areas.
• Q: Is this probe waterproof?
  A: The armor protects but connections need sealing.
• Q: What’s the cable’s bend radius?
  A: Minimum 25.4mm (1″) to prevent damage.
• Q: How accurate is this probe?
  A: Very precise – less than 2mV change per volt.
• Q: What maintenance is needed?
  A: Just check for physical damage periodically.
