A06B-6117-H303 FANUC 3-Axis Servo Drive 283-339VDC

FANUC A06B-6117-H303 – 3-Axis Servo Amplifier Module

This FANUC servo drive processes 283-339 VDC input and outputs 200-240 VAC at 0.1–800 Hz. Rated 1.5 kW, it delivers 3 A per axis (L, M, N). Compact 6.8 kg unit supports 0–55 °C and 90% RH. Ideal for multi-axis CNC and robotic applications.

Technical Data Sheet

• Brand: FANUC
• Model: A06B-6117-H303
• Series: A06B
• Type: Servo Amplifier Module
• Input Voltage: 283-339 VDC
• Input Frequency: 50/60 Hz
• Output Voltage: 200-240 VAC
• Output Frequency: 0.1 – 800 Hz
• Rated Output Current: 3 A (L-axis), 3 A (M-axis), 3 A (N-axis)
• Rated Input Power: 1.5 kW
• Operating Temperature: 0 to 55 °C
• Humidity: ≤90% RH (non-condensing)
• Weight: 6.80 kg (15.00 lbs)

Environmental & Mechanical Limits

• Ambient temp range: 0 to 55 °C for reliable operation.
• Humidity tolerance: up to 90% RH without condensation.
• Storage temp: -20 to 70 °C.
• Vibration: 5 to 55 Hz, 0.5 mm amplitude.
• Shock: 10 G, 11 ms half-sine.

Compatible Equipment

• ✅ FANUC CNC series 0i, 30i, 31i
• ✅ FANUC servo motors αi and βi series
• ✅ Robotic controllers R-30iA / R-30iB
• ✅ Linear and rotary servo axes
• ✅ Third-party motion controllers with DC bus

Installation & Commissioning

• Mount vertically on metal plate for heat dissipation.
• Use M4 screws with torque 1.8 N·m.
• Connect DC bus and motor cables per manual.
• Set axis parameters via FANUC software.
• LED status indicators: POWER, ALM, RDY.

Oiltech Controls’s Insight

• This 3-axis amplifier reduces panel space by 30% versus single-axis units.
• Wide output frequency range (0.1–800 Hz) supports high-speed spindle and positioning.
• Rated 3 A per axis – verify motor current before selection.
• Built-in overcurrent and thermal protection – no external relays needed.
• Common failure: DC bus fuse – replace with same rating.

Maintenance & Diagnostics

• Front LED code table – refer to manual for fault decoding.
• Monitor output current via analog test points.
• Fan cleaning every 6 months in dusty environments.
• Fault memory stores last 3 events.

5 Professional FAQs

• Q1: Can I use this for a 2-axis application?
  Yes, you can leave one axis unused. No software change required.
• Q2: What is the max cable length to motor?
  Keep motor cables under 20 meters for stable performance.
• Q3: Does it support absolute encoders?
  Yes, with FANUC serial encoder interface (αi/βi).
• Q4: How to choose between this and A06B-6117-H303#A?
  The H303 is base model; #A has enhanced EMI filter. Choose #A for noisy environments.
• Q5: What if output current exceeds 3 A?
  The amp will trip on overcurrent. Check motor load or reduce acceleration.
